Extron VGA M-M MD/6 VGA Male-to-Male Cable
- • 6' (1.8 m) male-to-male VGA cable on Extron MHRVGA cable
- • Molded 15-pin HD male connectors at both ends
- • Pin 9 +5 VDC and ID bits carried end to end (VESA DDC v3 source)
- • Overall foil shield inside the molded body limits EMI pickup
- • Grounded VGA shell adds ESD protection at both ends
- • Certified by Extron for AVEdge, Cable Cubby and HSA access enclosures
- • Current Extron part 26-238-01, stocked and supported by Ampronix
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron VGA M-M MD/6 (part number 26-238-01) — a 6' (1.8 m) male-to-male VGA cable on Extron MHRVGA cable with molded 15-pin HD connectors.
Six feet is the length that lives in every table box and every lectern drawer. It reaches a laptop set down anywhere on a normal meeting table, and it coils back into a Cable Cubby without a fight. Both ends are 15-pin HD male, so it is the lead a presenter actually picks up and plugs in. That also means it is the lead that gets yanked, which is why Extron molds the connector bodies onto the cable rather than assembling a backshell over it.
Key Capabilities
- Carries computer video and ID bit signals across a 6' (1.8 m) run
- Pin 9 +5 VDC and the ID bits travel end to end when the graphics card meets VESA DDC version 3
- Molded 15-pin HD male connectors at both ends
- VGA shell tied to ground for ESD protection
- Injection-molded body with an overall foil shield for EMI isolation
- Certified by Extron for AVEdge, Cable Cubby and HSA access enclosures
Where It Is Used
Conference tables with pop-up connectivity, huddle spaces, classroom lecterns, and any Cable Cubby or AVEdge enclosure where a presenter lead has to retract cleanly after every session. Also a common rack tie-line length.
Specifications at a Glance
- Cable length: 6' (1.8 m)
- Connectors: 2 male 15-pin HD, molded
- Cable: Extron MHRVGA
- DDC: pin 9 +5 VDC and all ID bits carried through (VESA DDC v3 source required)
- Status: current Extron part number
Also referenced as Extron VGAMMMD6, VGA-M-M-MD-6, part number 2623801.
