Extron VGA M-M MD/3 (part number 26-238-14) — a 3' (90 cm) male-to-male VGA jumper on Extron MHRVGA cable with molded 15-pin HD connectors.

Rack builders and furniture integrators buy this length by the box. Three feet is enough to get from an input plate to a switcher card, from a shelf-mounted source to the device above it, or out of a table box to a laptop sitting right beside it, with no service loop to hide. Both ends are 15-pin HD male. The molded bodies mean the shield is continuous through the termination, which matters more in a dense rack than it does on a long run.

Key Capabilities

• Carries computer video and ID bit signals across a 3' (90 cm) run
• Pin 9 +5 VDC and the ID bits travel end to end when the graphics card meets VESA DDC version 3
• Molded 15-pin HD male connectors at both ends
• VGA shell tied to ground for ESD protection
• Injection-molded body with an overall foil shield for EMI isolation
• Certified by Extron for AVEdge, Cable Cubby and HSA access enclosures

Where It Is Used

Equipment racks and patch fields, Cable Cubby and AVEdge enclosures where cable slack has nowhere to go, lectern interiors, and test benches where a short, robust lead is swapped between sources dozens of times a week.

Specifications at a Glance

• Cable length: 3' (90 cm)
• Connectors: 2 male 15-pin HD, molded
• Cable: Extron MHRVGA
• DDC: pin 9 +5 VDC and all ID bits carried through (VESA DDC v3 source required)
• Status: retired by Extron

Also referenced as Extron VGAMMMD3, VGA-M-M-MD-3, part number 2623814.
