Extron One USB 2.0 Type-A Female to USB Type-B Female Adapter (part number 70-383-11) — the black single-space MAAP barrel that puts a USB junction on the face of a plate instead of leaving it loose behind one.

The module is a passive barrel: a USB Type-A female opening on one side, a USB Type-B female opening on the other, carried on a mountable metal MAAP plate. Extron describes the barrel as reversible, so the integrator decides at install time which connector shows at the front of the plate and which faces into the enclosure. That single choice is what makes it useful — the same part number serves a table box that needs to present a host port and a rack plate that needs to present a device port.

Key Capabilities

• USB Type-A female to USB Type-B female pass-through in one barrel
• Reversible orientation — either connector can be the front-facing one
• Extron Barrel/Adapter module in the single-space MAAP size
• Black finish, the current colour in Extron's part table for this module
• No wiring, no soldering, no captive screws — it is a mechanical adapter
• Drops into Extron interfaces, MAAP frames and other MAAP-ready products

Where It Is Used

Extron places MAAP modules in walls, tables, podiums, floor boxes and equipment racks. A Type-A to Type-B barrel is the usual answer when a room PC, DSP, camera or interactive display has to be reachable from the surface of a plate — a lectern that hands a Type-B port to a visiting laptop cable, or a credenza plate that hands a Type-A port to a peripheral.

Specifications at a Glance

• Signal: USB 2.0
• Connectors: one USB Type-A female to one USB Type-B female
• Module type: Barrel/Adapter
• Module size: single space (MAAP)
• Finish: black

Extron does not publish plate dimensions, weight or a warranty figure for this module, so none are quoted here. Custom engraving is offered by Extron if the connector needs a label.

Also listed as One-USB-2.0-Type-A-Female-to-USB-Type-B-Female-Adapter, Extron part number 7038311.
