Extron MVGA M-M/3 (part number 26-567-01) — a 3 ft (90 cm) micro VGA cable with a 15-pin HD male connector at each end.

What separates this from a generic VGA lead is bulk. Extron uses an extremely thin cable with low-profile moulded connectors, which is why the assembly is certified to live inside AVEdge, Cable Cubby and HSA surface access enclosures where a standard VGA hood simply will not close the lid. Pin 9 is carried straight through, so a graphics card that follows VESA DDC version 3 can still read the display's ID bits and supply +5 VDC. The jacket is AWM 20276 rated.

Key Capabilities

• 3 ft (90 cm) length for short in-enclosure connections
• Male 15-pin HD connectors at both ends, moulded and low profile
• Pin 9 passed through end to end for ID bits and +5 VDC
• Extremely thin, flexible cable that coils inside a table box
• AWM 20276 rated jacket
• Certified for AVEdge, Cable Cubby and HSA enclosures

Where It Is Used

Table boxes and surface access enclosures in conference rooms and classrooms, lectern connectivity panels, and equipment furniture where a VGA source has to reach a switcher input a short distance away without a bulky cable hood in the way.

Specifications at a Glance

• Cable length: 3 ft (90 cm), measured neck-to-neck between strain reliefs
• Connectors: moulded 15-pin HD male at both ends
• Signals: computer video plus ID bits, pin 9 passed through
• Rating: AWM 20276

Also referenced as Extron MVGAM-M/3, MVGA-M-M-3, part number 2656701.
