Extron ISS 612 60-1685-01

Extron ISS 612 4K/60 HDMI DisplayPort 12G-SDI Switcher 60-1685-01

Extron ISS 612 4K/60 HDMI DisplayPort 12G-SDI Switcher 60-1685-01

Manufacturer: Extron

Type: Scalers & Signal Processors

Extron ISS 612 HDMI, DisplayPort & 12G-SDI Seamless Switcher

  • • Six HDMI, two DisplayPort, and four 12G-SDI inputs, HDCP 2.3
  • • Preview and Program outputs mirrored on HDMI and 12G-SDI
  • • Buffered 12G-SDI genlock input with loop-through for house sync
  • • Vector 4K scaling up to 4096x2160 at 60 Hz, 4:4:4
  • • True seamless switching with cut, dissolve, and wipe effects
  • • 2U rack-mount enclosure with 7-year Everlast power supply warranty

Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!

SKU: EXTRON-ISS612-60168501

Details

Extron ISS 612 (part number 60-1685-01) is a true seamless switcher with six HDMI, two DisplayPort, and four 12G-SDI inputs for live presentation and broadcast-style production.

Vector 4K scaling processes every source up to 4K/60 4:4:4, and independent Preview and Program buses let an operator confirm a source before sending it to the audience with a cut, dissolve, or wipe transition. Two HDMI outputs mirror to two 12G-SDI outputs, so a single switch feeds both a broadcast chain and a local display. A buffered 12G-SDI genlock input with loop-through synchronizes the switcher to house sync for production environments, and embedded HDMI, DisplayPort, or SDI audio switches along with video while de-embedded two-channel analog audio feeds a separate sound system.

Key Capabilities

  • Six HDMI 2.0, two DisplayPort 1.2, and four 12G-SDI inputs, HDCP 2.3
  • Preview and Program outputs mirrored across HDMI and 12G-SDI
  • Buffered 12G-SDI genlock input with loop-through for house sync
  • Vector 4K scaling up to 4096x2160 at 60 Hz, 4:4:4 chroma
  • Logo insertion, video keying, and picture-in-picture (PIP)
  • 2U rack-mount metal enclosure, 3.5 in H x 17.5 in W x 12.75 in D

Where It Is Used

Ampronix specifies the ISS 612 for live event venues, broadcast production suites, and command centers that mix HDMI, DisplayPort, and SDI camera feeds and need genlocked, seamless switching between them on both an HDMI and an SDI signal chain.

Specifications at a Glance

  • Inputs: 6 HDMI 2.0, 2 DisplayPort 1.2, 4 12G-SDI
  • Outputs: 2 HDMI + 2 12G-SDI (Preview/Program, mirrored)
  • Video: Vector 4K scaling, 4K/60 4:4:4; SDI to 11.88 Gbps
  • Enclosure: 3.5 in (2U) high, full rack wide
  • Warranty: 7-year Everlast power supply warranty

Also referenced as Extron ISS612, ISS-612, part number 60168501.
