Extron FOX3 Matrix 560x/840x Power Supply Kit (part number 70-1230-01) — the hot-swappable replacement power supply module shared by the Extron FOX3 Matrix 560x and FOX3 Matrix 840x fiber optic matrix switchers.

Both the 560x and 840x ship with redundant power supplies as standard on a high-current IEC 60320 C20 inlet rated 200-240 VAC, since a fully loaded 40-slot frame at this scale draws well beyond what a residential-style connector or 120 VAC branch circuit can safely supply. This kit is the direct replacement or spare for either the primary or redundant position on either chassis, and it is hot-swappable, so it installs or replaces without powering down the switcher or dropping 4K/60 video, audio, USB, and control signal routing already in progress.

Key Capabilities

• Hot-swappable, installs or replaces without powering down the switcher
• High-current IEC 60320 C20 inlet, 200-240 VAC, 50-60 Hz
• North America: single phase, 200-240 VAC, 50-60 Hz, 20 A protected source
• One kit covers both the FOX3 Matrix 560x and FOX3 Matrix 840x frames
• Matches either the primary or standard redundant supply position

Where It Is Used

Large-venue and enterprise deployments running a fully loaded FOX3 Matrix 560x or 840x — stadiums, broadcast centers, and government command facilities — stock this kit to restore mandatory redundant power after a supply fault.

Specifications at a Glance

• Compatibility: FOX3 Matrix 560x and FOX3 Matrix 840x chassis
• Connector: IEC 60320 C20 inlet
• Input: 200-240 VAC, 50-60 Hz
• Hot-swappable, tool-free installation

Also referenced as Extron FOX3Matrix560x840xPowerSupplyKit, FOX3-Matrix-560x-840x-Power-Supply-Kit, part number 70123001.
