Extron FOX3 I/O 88 SM (part number 70-1107-02) — the singlemode 8x8 fiber optic I/O board used to build or expand Extron FOX3 Matrix 40x, 80x, 160x, 320x, 560x, and 840x switchers.

Every FOX3 Matrix frame from the 40x through the 840x is assembled from individual 8-in by 8-out I/O boards, and this is the singlemode version, carrying 8 singlemode SFPs behind 16 LC connectors for long-haul fiber runs. Integrators add boards to grow a matrix from its base configuration toward its maximum size, or swap one in as a hot-swappable replacement for a failed board, without powering down the frame or interrupting signal routing on the remaining boards.

Key Capabilities

• 8 singlemode SFPs per board, 16 LC connectors, hot-swappable
• Up to 20 km (12.4 miles) reach on singlemode fiber
• Carries 4K/60 4:4:4 video, audio, USB, control, and 3D sync over each fiber link
• 10 Gbps per-channel data rate, HDMI 2.0 and HDCP 2.3 compliant signal path
• Compatible with FOX3 Matrix 40x, 80x, 160x, 320x, 560x, and 840x frames

Where It Is Used

This board is specified for FOX3 Matrix installations that span buildings or campuses beyond multimode reach — university and hospital campuses, stadiums, and any facility connecting distribution rooms over kilometers of singlemode fiber.

Specifications at a Glance

• Number/type: 8 singlemode SFPs per board
• Connectors: 16 LC connectors per board
• Operating distance: 20 km (12.4 miles), singlemode fiber
• Nominal wavelength: 1310 nm

Because the FOX3 Matrix accepts any mix of multimode and singlemode boards in the same frame, integrators commonly pair this board with FOX3 I/O 88 MM boards on the same switcher to bridge in-building multimode runs with campus-length singlemode links.

Also referenced as Extron FOX3IO88SM, FOX3-I-O-88-SM, part number 70110702.
