Extron FOX3 80x/320x Fan Kit (part number 70-1120-02) — the hot-swappable replacement fan assembly shared by the Extron FOX3 Matrix 80x and FOX3 Matrix 320x fiber optic matrix switchers.

Both the FOX3 Matrix 80x and FOX3 Matrix 320x cool with a fan assembly that draws air right to left as viewed from the front panel, and Extron uses the same replacement module for both frames. When a fan fails, this hot-swappable kit slides into the chassis opening without requiring a power-down or interrupting the 4K/60 video, audio, USB, and control signals already routed through the switcher. Captive panel screws make the swap tool-light for a field technician.

Key Capabilities

• Hot-swappable, installs or replaces without powering down the switcher
• Matches the chassis-specified right-to-left cooling airflow
• One kit covers both the FOX3 Matrix 80x and FOX3 Matrix 320x frames
• Tool-free captive panel screws for fast field service

Where It Is Used

Facilities and integration teams supporting a FOX3 Matrix 80x or 320x in continuous operation stock this kit as a single maintenance spare, since a failed fan reduces cooling margin on a fully populated frame carrying 4K/60 signal traffic.

Specifications at a Glance

• Compatibility: FOX3 Matrix 80x and FOX3 Matrix 320x chassis
• Airflow: fan-driven, right to left as viewed from the front panel
• Hot-swappable, tool-free captive panel screws

Standardizing the fan assembly across the 80x and 320x frames simplifies spares inventory for integrators who deploy both chassis sizes, since a single stocked kit services either unit.

Also referenced as Extron FOX380x320xFanKit, FOX3-80x-320x-Fan-Kit, part number 70112002.
