Extron FOX3 40x P/S Kit (part number 70-1119-01) — the hot-swappable replacement power supply module for the Extron FOX3 Matrix 40x fiber optic matrix switcher.

The FOX3 Matrix 40x ships with redundant power supplies as standard, so this kit supplies a direct replacement for either the primary or redundant unit. Built as a hot-swappable 100-240 VAC module on an IEC 60320 C14 inlet, it installs or replaces without powering down the switcher, so the 4K/60 video, audio, USB, and control signals already routed through the 40x chassis continue uninterrupted while a technician services the supply.

Key Capabilities

• Hot-swappable, installs or replaces without powering down the FOX3 Matrix 40x
• Universal 100-240 VAC, 50-60 Hz input through an IEC 60320 C14 inlet
• Matches either the primary or the standard redundant supply position
• Front panel LED reports power supply status once installed
• Purpose-built for the FOX3 Matrix 40x frame only

Where It Is Used

Integrators supporting a FOX3 Matrix 40x in mission-critical service — command and control rooms, broadcast facilities, and higher-education AV backbones — use this kit to keep the standard redundant power configuration intact after a supply fault.

Specifications at a Glance

• Compatibility: FOX3 Matrix 40x chassis (8x8 up to 40x40) only
• Input: 100-240 VAC, 50-60 Hz
• Connector: IEC 60320 C14 inlet
• Hot-swappable, tool-free installation

Because the primary and redundant supplies on the 40x are identical and hot-swappable, this single kit works in either bay, simplifying spares planning for integrators who standardize on the 40x chassis.

Also referenced as Extron FOX340xPSKit, FOX3-40x-P-S-Kit, part number 70111901.
