Extron FOX Matrix Blank Plate (part number 70-651-21) — a single-slot filler panel for an unpopulated I/O board position in a FOX Matrix frame.

Extron's FOX Matrix 3200 is a four-slot card cage, and it is designed to run with some or all of those slots occupied. Any position without a FOX I/O 88 board fitted needs a cover, and this is the part Extron lists for the job: one plate per empty slot. A frame bought as an 8x8 and later grown toward 32x32 will therefore need two or three of these on day one, with plates coming off as boards go in.

Key Capabilities

• Closes one empty I/O board slot on a FOX Matrix frame
• Matches the metal enclosure of the FOX Matrix 3200 chassis
• Lets a partially populated frame be shipped, racked and operated as delivered
• Removable as the frame is expanded with additional FOX I/O 88 multimode or singlemode boards
• One plate is required for each of the four slots left unoccupied

Where It Is Used

Anywhere a FOX Matrix 3200 is deployed below its full 32x32 capacity — phased campus fiber rollouts, hospital imaging distribution, simulation ranges, broadcast facilities and command centers that specify the frame first and add I/O cards as the system grows.

Specifications at a Glance

• Extron part number: 70-651-21
• Coverage: one single I/O slot
• Fits: FOX Matrix 3200 modular fiber optic matrix switcher, 4U full-rack frame
• Frame capacity: four I/O board slots

Also referenced as Extron FOXMatrixBlankPlate, FOX-Matrix-Blank-Plate, part number 7065121.
