Extron FOX Matrix 3200 Power Supply Kit (part number 70-710-01) — the factory replacement power supply assembly for the FOX Matrix 3200 fiber optic matrix switcher frame.

The FOX Matrix 3200 ships with two internal supplies arranged as a primary and a redundant unit, and Extron makes both hot-swappable. This kit is the spare for that pair. Because a healthy second supply keeps the frame running when the first one drops out, replacing a failed unit is a scheduled task rather than an outage — the switcher's real-time monitoring flags the fault, and the module comes out while fiber routing carries on. Ampronix supplies the kit for teams maintaining installed FOX Matrix 3200 frames.

Key Capabilities

• Direct replacement supply for the FOX Matrix 3200 modular fiber matrix switcher
• Hot-swappable: the module is exchanged without powering the chassis down
• Restores the frame's standard primary-plus-redundant supply pairing
• Accepts 100-240 VAC at 50-60 Hz for use on both domestic and international mains
• Covers a frame drawing 31.4 W bare and up to 87.0 W with four singlemode I/O cards fitted

Where It Is Used

FOX Matrix 3200 frames sit at the centre of fiber AV backbones in hospitals, universities, stadiums, simulation and defense facilities, broadcast plants and command centers. Sites running around the clock hold a spare supply so redundancy is restored the same day a module is flagged.

Specifications at a Glance

• Extron part number: 70-710-01
• Fits: FOX Matrix 3200 modular fiber optic matrix switcher
• AC input: 100-240 VAC, 50-60 Hz
• Configuration: one of two internal supplies, primary and redundant, hot-swappable

Also referenced as Extron FOXMatrix3200PowerSupplyKit, FOX-Matrix-3200-Power-Supply-Kit, part number 7071001.
