Extron FOX I/O 1616 HD-SDI 16x16 3G-SDI Matrix I/O Board
- • 16 single link SDI, HD-SDI or 3G-SDI I/O, or 8 dual link HD-SDI, per board
- • 32 female BNC terminations at 75 ohms and 0.80 Vp-p nominal
- • Automatic data rate lock to 2.97 Gbps with 8 or 10 bit data
- • SDI inputs equalize out to 1230 ft (357 m) on Extron RG6 or Belden 1694A
- • Immune to pathological signals per SMPTE RP 178 and RP 198
- • Automatic output reclocking, with bypass for nonstandard rates
- • Jitter below 0.2 UI; rise and fall time 600 ps plus or minus 200 ps
- • Hot-swappable card for FOX Matrix 320x and FOX Matrix 14400 frames
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron FOX I/O 1616 HD-SDI (part number 70-966-01) — a 16x16 3G-SDI, HD-SDI and SDI input/output board for Extron FOX Matrix modular switchers.
Unlike the fiber cards in the same family, this board terminates in coax: sixteen female BNC inputs and sixteen female BNC outputs on one slot. It lets a FOX Matrix 320x or FOX Matrix 14400 accept and deliver baseband serial digital video directly, so a fiber routing plant and local SDI gear can live inside a single frame. Data rates up to 2.97 Gbps are locked automatically, incoming signals are equalized on arrival, and outputs are reclocked — or bypassed when a nonstandard rate has to pass untouched. Each input and output is individually buffered.
Key Capabilities
- 16 single link SDI, HD-SDI or 3G-SDI inputs and outputs — or 8 dual link HD-SDI per board
- 32 female BNC terminations per card, 75 ohms, 0.80 Vp-p nominal
- Automatic data rate lock up to 2.97 Gbps with 8 or 10 bit data
- SDI input runs to 1230 ft (357 m) on Extron RG6 or Belden 1694A cable
- Immune to pathological signals, including SMPTE RP 178 and RP 198 test patterns
- Compliant with SMPTE 292M, 259M, 297-2006 and 424M plus ITU-RBT.601 and ITU-RBT.1120
Where It Is Used
This card is the bridge between a fiber matrix and local broadcast equipment: production control rooms, master control and playout areas, post and editing suites, medical imaging and surgical video, stadium and arena video systems, and defense or simulation facilities that mix long-haul fiber links with racked SDI sources and monitors.
Specifications at a Glance
- Maximum data rate: 2.97 Gbps, automatic rate lock
- Input return loss >13 dB and output return loss >11 dB, 1 MHz to 1.3 GHz
- Jitter under 0.2 UI; rise and fall time 600 ps ±200 ps
- Board power draw: 26.2 watts
- Operating range: +32 to +104 °F (0 to +40 °C), 10% to 90% noncondensing
Also referenced as Extron FOXIO1616HDSDI, FOX-I-O-1616-HD-SDI, part number 7096601.
