Extron EWB 211 (part number 70-1131-11) — the one-gang white member of the EWB 210 Series, an EU-format surface box for Flex55 and EU devices.

European wall construction and EU device formats need their own enclosure, and the EWB 211 is Extron's answer for a single gang. Moulded from high impact plastic, it measures 85 by 85 mm on the wall with 47 mm of internal depth, and it mounts either directly to the wall using its four wall holes or onto an existing EU junction box using the two mounting holes at 60 mm centres. Devices attach with M3 screws through two device mounting points, and two knockout covers close off the raceway openings that are not used.

Key Capabilities

• One-gang EU box for Flex55 mounting kits and EU wallplate devices
• Enclosure of 3.35 in H x 3.35 in W x 1.97 in D (85 x 85 x 50 mm)
• 1.85 in (47 mm) internal depth for cabling and connectors
• Two raceway openings, one on each side, with two knockout covers
• Mounts to a wall or to an EU junction box at 60 mm centres
• Weighs only 0.14 lb (0.06 kg); CE, RoHS and WEEE compliant

Where It Is Used

European and international meeting rooms, teaching spaces and clinical corridors running Flex55 modules, MLC and NBP EU control panels, where the wall cannot take a recessed EU junction box.

Specifications at a Glance

• Configuration: one-gang EU, wall mount
• Material: high impact plastic
• Product weight: 0.14 lb (0.06 kg)
• Regulatory: CE, RoHS, WEEE
• Warranty: 3 years parts and labor

Also referenced as Extron EWB211, EWB-211, part number 70113111.
