Extron EWB 107 (part number 60-689-02) — the seven-gang black external wall box in Extron's EWB Series, and the widest configuration the series offered. Now a retired part number.

Seven gangs is what a consolidated AV wall becomes when transmitters, control panels, audio, USB and pass-through plates all have to share one location. The EWB 107 supports that on the surface of an interior wall with no recessed back box required. It keeps the 2.5 inch (6.4 cm) depth that runs through the EWB Series, which is what a faceplate needs once connector bodies and slack cable are behind it, and its knockouts let cable enter from a surface raceway channel or from the wall space at the rear.

Key Capabilities

• Seven-gang opening for Extron wallplates, AAP frames and control panels
• 2.5 in (6.4 cm) EWB Series depth for faceplate wiring and service loop
• Knockouts for external surface raceway cable channels
• Steel construction for permanent architectural surface mounting
• Black finish — the -02 version of the 60-689 part series
• Covered by Extron's 3 year parts and labor warranty

Where It Is Used

Large lecture theatres, divisible ballrooms, broadcast facilities and command centers where a single wall drop consolidates many subsystems. Also specified on masonry, glass-backed and demountable walls that cannot take an in-wall enclosure.

Specifications at a Glance

• Configuration: seven-gang, wall mount
• Material: steel
• Depth: 2.5 in (6.4 cm)
• Cable entry: surface raceway knockouts or rear wall space
• Warranty: 3 years parts and labor

Also referenced as Extron EWB107, EWB-107, part number 6068902.
