Extron DTP T DP 4K 330 DisplayPort Twisted Pair Transmitter
- • Full 330 ft (100 m) reach at 1080p, 2560x1600 and 4K/UHD alike, no derating
- • DTP 330 link on a single female RJ-45, terminated TIA/EIA T568B
- • One female DisplayPort input, DisplayPort 1.1a with HDCP 1.4 and 2.3
- • Up to 10.8 Gbps (2.7 Gbps per lane) at a 300 MHz transmitter pixel clock
- • Analog stereo audio input on a 3.5 mm jack, -10 dBV nominal, +7 dBV max
- • RS-232 to 115200 baud and 30-60 kHz IR share one 5-pole captive screw port
- • 3.4 W device draw, 4.8 W with supply, 12 W remote power budget
- • Vent-free quarter-rack metal enclosure at 0.5 lbs (0.3 kg)
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron DTP T DP 4K 330 (part number 60-1076-52) — the long-reach DisplayPort sending unit in the DTP 330 twisted pair family.
Where the 230-class unit tapers off at higher resolutions, this transmitter holds a full 330 ft (100 m) at every rated resolution, including 4K and UHD at 30 Hz. One shielded twisted pair run terminated to TIA/EIA T568B carries the DisplayPort picture, its embedded digital audio, an additional analog stereo feed, and bidirectional RS-232 and IR control. Order the matching DTP R DP 4K 330 receiver separately to complete the link.
Key Capabilities
- Holds 330 ft (100 m) at 1080p 60 Hz, at 2560x1600 60 Hz and at 4K/UHD 30 Hz alike — no resolution-dependent derating.
- One female DisplayPort input running DisplayPort 1.1a with HDCP 1.4 and 2.3, Single Stream Transport only.
- Throughput up to 10.8 Gbps, 2.7 Gbps per lane, with a 300 MHz transmitter pixel clock.
- Analog stereo audio arrives on a 3.5 mm jack at -10 dBV nominal, greater than 10k ohms DC coupled, +7 dBV maximum unbalanced.
- RS-232 from 300 to 115200 baud and TTL-level IR from 30 kHz to 60 kHz share a 5-pole captive screw port.
- 3.4 watt device draw, 4.8 watts with the supply, and a 12 watt remote power budget for one-ended powering.
Where It Is Used
Built for the runs a 230-class extender cannot finish: divisible ballrooms, large lecture theatres, auditorium projection booths, hospital and imaging corridors, and command centers where the DisplayPort source stays locked in a distant rack. Vent-free convection cooling suits sealed lecterns and credenzas.
Specifications at a Glance
- Link type: DTP 330 on a female RJ-45, one per unit.
- Cable: solid conductor 24 AWG or better; 400 MHz bandwidth STP recommended.
- Enclosure: metal, quarter rack wide, 1.0 in H x 4.3 in W x 6.0 in D, 0.5 lbs (0.3 kg).
- Thermal load: 11.6 BTU/hr device, 16.1 BTU/hr with the power supply.
- Warranty: 3 years parts and labor, with 7 years on the Everlast power supply.
Also referenced as Extron DTPTDP4K330, DTP-T-DP-4K-330, part number 60107652.
