Extron DTP R DP 4K 330 (part number 60-1076-63) — the 100 metre DisplayPort receiver in Extron's DTP 330 twisted pair range.

This is the display-side unit. It terminates a DTP 330 link on a single female RJ-45 and regenerates a DisplayPort video output, a two-channel analog audio output, and RS-232 and IR signalling for whatever is connected downstream. Unlike the 230-class receiver, it keeps the full 330 ft (100 m) run at every rated resolution, so a 4K feed does not force a shorter cable route. Pair it with a DTP T DP 4K 330 transmitter, ordered separately.

Key Capabilities

Full 330 ft (100 m) reach at 1080p 60 Hz, 2560x1600 60 Hz and 4K/UHD 30 Hz, with no step-down.
One female DisplayPort output, DisplayPort 1.1a with HDCP 1.4 and 2.3, Single Stream Transport.
268 MHz receiver pixel clock on a link carrying up to 10.8 Gbps, 2.7 Gbps per lane.
Analog audio output above +14 dBu balanced into 600 ohms, with 0.2 dB channel-to-channel gain error.
Handles embedded PCM, Dolby Digital 2/0 and DTS Digital Surround 5.1 material at 48 kHz, 16 bit.
Local RS-232 on a 3-pole captive screw connector plus IR pass-through from 30 kHz to 60 kHz.

Where It Is Used

Suits venues where the display sits far from the equipment room: auditoriums, multipurpose halls, large classrooms, hospital and laboratory corridors, and multi-position control rooms. Convection cooling with no vents lets it sit inside enclosed millwork or a display mount without airflow provision.

Specifications at a Glance

Link: DTP 330 signal type, TIA/EIA T568B termination, 24 AWG or better solid conductor STP.
Power: 5.5 watts device, 6.8 watts with the supply, 12 watt remote power budget.
Thermal load: 17.6 BTU/hr device, 21.9 BTU/hr with the power supply.
Enclosure: metal, quarter rack wide, 1.0 in H x 4.3 in W x 6.0 in D, 1.0 lb (0.5 kg).
Warranty: 3 years parts and labor; Everlast power supply 7 years.

Also referenced as Extron DTPRDP4K330, DTP-R-DP-4K-330, part number 60107663.

Specifications

Part Number: 60-1076-63

Manufacturer: Extron

Model: DTP R DP 4K 330 (receiver)

Condition: New

Signal Type: DisplayPort, HDCP

Maximum Data Rate: Up to 10.8 Gbps (2.7 Gbps per lane)

Maximum Pixel Clock: 268 MHz

Resolution Range: Up to 2560x1600 @ 60 Hz (reduced blanking), 4K (4096x2160) @ 30 Hz, UHD (3840x2160) @ 30 Hz

Frame Rate: 24, 25, 30 fps (subject to the maximum data rate limit)

Chroma Sampling: 4:4:4 or 4:2:2

Color Bit Depth: 8, 10, or 12 bits - subject to the maximum data rate limit

Formats: RGB and YCbCr digital video

Standard: DisplayPort 1.1a, HDCP 1.4, 2.3 (Single Stream Transport only)

Video Output: 1 DisplayPort

Video Output Connector: 1 female DisplayPort

Interconnection Signal Type: DTP 330

Interconnection Connector: 1 female RJ-45 per unit

Termination Standard: TIA/EIA T568B

Transmission Distance, 1080p @ 60 Hz: Up to 330 ft (100 m) on shielded twisted pair (STP) or XTP DTP 24 STP cable

Transmission Distance, 2560x1600 @ 60 Hz: Up to 330 ft (100 m) on shielded twisted pair (STP) or XTP DTP 24 STP cable

Transmission Distance, 4K/UHD @ 30 Hz: Up to 330 ft (100 m) on shielded twisted pair (STP) or XTP DTP 24 STP cable

Cable Requirements: Solid conductor, 24 AWG or better

Cable Recommendations: 400 MHz bandwidth, STP (shielded twisted pair)

Audio Gain: Unbalanced output 0 dB; balanced output +6 dB

Audio Frequency Response: 20 Hz to 20 kHz, plus or minus 0.5 dB

THD + Noise: 0.03% @ 20 Hz to 20 kHz at maximum output

Signal-to-Noise Ratio: Greater than 90 dB at maximum input (unweighted)

Stereo Channel Separation: Greater than 80 dB

Digital Sampling: 48 kHz

Audio Bit Depth: 16 bit

Audio Output Signal Type: Analog stereo (2 channel), balanced/unbalanced over DTP; embedded digital audio on the DTP signal

Embedded Digital Audio Source Formats: 2-ch PCM, PCM, Dolby Digital 2/0 Surround, Dolby Digital 2/0, DTS Digital Surround 5.1, DTS-ES Matrix 6.1, DTS-ES Discrete 6.1

Audio Output Impedance: 50 ohms unbalanced, 100 ohms balanced

Audio Output Gain Error: Plus or minus 0.2 dB channel to channel

Audio Output Maximum Level (600 ohm): Greater than +14 dBu, balanced

Audio Output Connector, Digital: Female DisplayPort

Audio Output Connector, Analog: (1) 3.5 mm captive screw connector, 5 pole

Serial Control Port Input/Output: 1 set of proprietary signals on a female RJ-45 jack

Serial Control Port Output/Input: RS-232 via a 3.5 mm, 3 pole captive screw connector

Baud Rate and Protocol: 300 to 115200 baud, 8 or 7 data bits, 1 or 2 stop bits, non-parity (default), even or odd parity

Serial Control Pin Configuration: 1 = Tx, 2 = Rx, 3 = Gnd

IR Control Port: (1) 3.5 mm captive screw connector, 5 pole (shared with the RS-232 control port); TTL level (0 to 5 V) modulated infrared control from 30 kHz up to 60 kHz

IR Control Pin Configuration: 3 = Gnd, 4 = IR Tx, 5 = IR Rx

Power Supply: External. Input: 100-240 VAC, 50-60 Hz. Output: 12 VDC, 1.5 A, 18 watts

Power Consumption, Device: 5.5 watts

Power Consumption, Device and Power Supply: 6.8 watts

Remote Power Budget: 12 watts

Temperature/Humidity: Storage -40 to +158 F (-40 to +70 C) / 10% to 90%, noncondensing. Operating +32 to +122 F (0 to +50 C) / 10% to 90%, noncondensing

Cooling: Convection, no vents

Thermal Dissipation, Device: 17.6 BTU/hr

Thermal Dissipation, Device and Power Supply: 21.9 BTU/hr

Rack Mount: Yes, with optional 1U high rack shelf

Furniture Mount: Yes, with optional under-desk mounting kit

Enclosure Type: Metal

Enclosure Dimensions: 1.0 in H x 4.3 in W x 6.0 in D, quarter rack wide (2.5 cm H x 10.9 cm W x 15.2 cm D); depth excludes connectors

Product Weight: 1.0 lb (0.5 kg)

Regulatory Compliance: CE, c-UL, UL, C-tick, FCC Class A, ICES, VCCI

Product Warranty: 3 years parts and labor

Everlast Power Supply Warranty: 7 years parts and labor

Diagram

Resources

Brochure | DTP R DP 4K 330 60-1076-63 | DTP DP 4K 230 (dtp_dp_4k_230_bro_vA4.pdf)

Brochure | DTP R DP 4K 330 60-1076-63 | Extron Government Solutions

Brochure | DTP R DP 4K 330 60-1076-63 | DTP DP 4K 230 (DTP-DP-4K-230_BR_A4_SP_RevA1.pdf)

Brochure | DTP R DP 4K 330 60-1076-63 | DTP DP 4K 230 (dtpdp4k230_bro_A1_cn.pdf)

Brochure | DTP R DP 4K 330 60-1076-63 | Extron-Lösungen für Behörden

Brochure | DTP R DP 4K 330 60-1076-63 | Solutions Extron pour structures gouvernementales

Brochure | DTP R DP 4K 330 60-1076-63 | Soluzioni Extron per ambienti governativi

Manual | DTP R DP 4K 330 60-1076-63 | Cleaning Instruction Card

Manual | DTP R DP 4K 330 60-1076-63 | DTP Compatibility Guide

Manual | DTP R DP 4K 330 60-1076-63 | DTP T/R DP 4K Series Setup Guide

Manual | DTP R DP 4K 330 60-1076-63 | DTP T/R DP 4K Series User Guide

Manual | DTP R DP 4K 330 60-1076-63 | DTP互換性ガイド

Specifications | DTP R DP 4K 330 60-1076-63 | DTP T/R DP 4K 230

Panel Drawing | DTP R DP 4K 330 60-1076-63 | DTP R DP 4K 230
