Extron DTP HDMI 4K 330 Tx HDMI Twisted Pair Transmitter
- • Sends every rated format the full 330 ft (100 m), 4K included
- • One STP run carries video, analog audio, RS-232 and IR
- • 4K/UHD at 60 Hz via 4:2:0 chroma subsampling, HDCP 2.3
- • 10.2 Gbps data rate and 300 MHz maximum pixel clock
- • 3.5 mm stereo input, -10 dBV nominal, +6 dBV maximum
- • RS-232 to 115200 baud shares the 5-pole port with IR
- • Draws 2.5 W, or takes remote power within a 12 W budget
- • 0.5 lb quarter-rack metal case, UL 2043 plenum rated
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron DTP HDMI 4K 330 Tx (part number 60-1331-12) — the source-side transmitter of Extron's DTP HDMI 330 4K pair, rated to a hundred metres at every format it carries.
Feed it from a laptop, camera, player or codec through its single female HDMI type A input; DVI-D sources work with an appropriate cable or adapter. Video, a PC-level analog stereo feed on a 3.5 mm jack, RS-232 and infrared all leave together on one female RJ-45, terminated to TIA/EIA T568B. The headline difference against the shorter 230 model is that 4K, UHD and 2560x1600 do not cost you any reach: Extron rates all of them, and 1080p at 60 Hz, to the same 330 feet. Its matching DTP HDMI 4K 330 Rx receiver is sold on its own.
Key Capabilities
- Drives 330 feet (100 m) at 1080p/60, 2560x1600/60, and 4K or UHD at 30 Hz and 60 Hz
- Passes 4096x2160 and 3840x2160 sources, reaching 60 Hz through 4:2:0 chroma subsampling
- 10.2 Gbps maximum data rate with a 300 MHz maximum pixel clock and HDCP 2.3
- Analog stereo input sits at -10 dBV nominal with a +6 dBV unbalanced maximum
- RS-232 runs to 115200 baud on a 5-pole captive screw shared with 30 kHz to 60 kHz IR
- Only 2.5 watts at the device, or remote powered from the receiver inside 12 watts
Where It Is Used
Long-run installations are the point here: stadium and worship-venue lecterns, university auditoriums, multi-storey office buildings where the rack and the display sit on different floors, and clinical or command spaces where the workstation must stay far from the viewing wall.
Specifications at a Glance
- Reach: 330 ft (100 m) across all rated resolutions including 4K/UHD
- Video input: 1 female HDMI type A, single link HDMI or DVI-D
- Cable: solid conductor 24 AWG or better shielded twisted pair, 400 MHz
- Enclosure: metal, 1.0 in H x 4.3 in W x 3.0 in D, quarter rack wide, 0.5 lbs (0.3 kg)
- Thermal dissipation: 7.4 BTU/hr device, 10.4 BTU/hr with the power supply
Also referenced as Extron DTPHDMI4K330Tx, DTP-HDMI-4K-330-Tx, part number 60133112.
