Details

Extron DTP DVI 4K 330 Tx (part number 60-1360-12) — the source-end unit of Extron's DTP DVI 4K 330 extension pair, driving DVI, stereo audio and control a full 100 metres down one twisted pair run.

The defining figure here is that 330' (100 m) applies uniformly: 1080p at 60 Hz, 2560x1600 at 60 Hz and 4K/UHD at 30 or 60 Hz all reach the same distance on shielded twisted pair. This transmitter takes one single link DVI-D feed on a female DVI-I port, mirrors it to a second DVI-I port for a local confidence monitor, and sends the signal plus RS-232 and infrared to a matching DTP DVI 4K 330 Rx. The two halves are ordered separately, and either can power the other over the link.

Key Capabilities

One single link DVI-D input plus one local DVI-D loop-through, on two female DVI-I connectors.
330' (100 m) reach at 1080p 60 Hz, 2560x1600 60 Hz and 4K/UHD at 30 or 60 Hz alike.
300 MHz maximum pixel clock and a 10.2 Gbps ceiling, at 8, 10 or 12 bits per color.
RS-232 on a 5-pole captive screw connector shared with the TTL IR port, 30 kHz to 60 kHz.
Unbalanced PC-level stereo input on a 3.5 mm jack, greater than 10k ohms and DC coupled.
Draws 3.4 watts and can be powered remotely across the link within a 12 watt budget.

Where It Is Used

Ampronix ships this transmitter into auditoriums, stadium and campus signage, multi-room training facilities, command centers, courtrooms and medical imaging suites — sites where the source has to stay in a secure rack and the cable run to the display comfortably exceeds what a 70 metre extender can carry at 4K.

Specifications at a Glance

Resolution range: 2560x1600 at 60 Hz with reduced blanking, 4096x2160 at 30 Hz, and 4K/UHD at 60 Hz when 4:2:0 chroma subsampling is used.
Link: one female RJ-45, TIA/EIA T568B, solid 24 AWG or better STP rated at 400 MHz.
Metal quarter-rack enclosure, 1.0 in H x 4.3 in W x 3.0 in D, 0.5 lbs (0.3 kg).
Thermal dissipation 10.3 BTU/hr; operating range +32 to +122 °F (0 to +50 °C).
Three-year parts and labor warranty; Everlast power supply carries seven years.

Also referenced as Extron DTPDVI4K330Tx, DTP-DVI-4K-330-Tx, part number 60136012.

Specifications

Part Number: 60-1360-12

Manufacturer: Extron

Model: DTP DVI 4K 330 Tx

Condition: New

Maximum Data Rate: 10.2 Gbps (3.4 Gbps per color)

Maximum Pixel Clock: 300 MHz

Resolution Range: Up to 2560x1600 @ 60 Hz (reduced blanking), or 4K (4096x2160) @ 30 Hz, UHD (3840x2160) @ 30 Hz, 4K/UHD @ 60 Hz with 4:2:0 chroma subsampling

Color Bit Depth: 8, 10, or 12 bits, subject to the maximum data rate limit

Frame Rate: 24, 25, 30, 50, or 60 fps

Chroma Sampling: 4:4:4, 4:2:2, or 4:2:0

Formats: RGB and YCbCr digital video

Standards: DVI 1.0, HDMI 1.4, HDCP 2.3, CEA-861E

Signal Type: HDMI 1.4, HDCP 2.3

Video Input - Number/Signal Type: 1 single link DVI-D (or HDMI with appropriate cable or adapter) input; 1 single link DVI-D (or HDMI) local loop-through

Video Input - Connectors: 2 female DVI-I

Interconnection Connector: 1 female RJ-45 per unit

Termination Standard: TIA/EIA T568B

Transmission Distance - 1080p @ 60 Hz: Up to 330' (100 m) over shielded twisted pair (STP) or XTP DTP 24 STP cable

Transmission Distance - 2560x1600 @ 60 Hz: Up to 330' (100 m) over shielded twisted pair (STP) or XTP DTP 24 STP cable

Transmission Distance - 4K/UHD @ 30 Hz and 60 Hz: Up to 330' (100 m) over shielded twisted pair (STP) or XTP DTP 24 STP cable

Cable Requirements: Solid conductor, 24 AWG or better

Cable Recommendations: 400 MHz bandwidth, STP (shielded twisted pair)

Audio Gain: Unbalanced output 0 dB; balanced output +6 dB

Audio Frequency Response: 20 Hz to 20 kHz, plus or minus 0.5 dB

THD + Noise: 0.03% @ 20 Hz to 20 kHz at maximum output

Signal-to-Noise Ratio: Greater than 90 dB at maximum output (15 dBu), balanced (unweighted)

Stereo Channel Separation: Greater than 80 dB @ 1 kHz to 20 kHz

Audio Input - Number/Signal Type: 1 PC level stereo, unbalanced

Audio Input - Connectors: (1) 3.5 mm stereo jack, 2 channel; tip (L), ring (R), sleeve (ground)

Audio Input - Impedance: Greater than 10k ohms, DC coupled

Audio Input - Nominal Level: -10 dBV (316 mVrms)

Audio Input - Maximum Level: +6 dBV (unbalanced)

Audio Output - Number/Signal Type: 1 stereo (2 channel), balanced/unbalanced

Audio Output - Connectors: (1) 3.5 mm captive screw connector, 5 pole

Audio Output - Impedance: 50 ohms unbalanced, 100 ohms balanced

Audio Output - Gain Error: Plus or minus 0.1 dB channel to channel

Audio Output - Maximum Level (600 ohm): Greater than +11 dBu, balanced

Serial Control Port Input (Transmitter): RS-232 via (1) 3.5 mm, 5 pole captive screw connector for RS-232 control (plus or minus 5 V); connector is shared with the IR control port

Serial Control Port Output (Transmitter): 1 set of proprietary signals on a female RJ-45 jack

Baud Rate and Protocol: 300 to 115200 baud, 8 or 7 data bits, 1 or 2 stop bits, non-parity (default), even or odd parity

Serial Control Pin Configuration: 1 = Tx, 2 = Rx, 3 = Gnd

IR Control Port: (1) 3.5 mm captive screw connector, 5 pole (shared with the RS-232 control port); TTL level (0 to 5 V) modulated infrared control from 30 kHz up to 60 kHz

IR Control Pin Configuration: 3 = Gnd, 4 = IR Tx, 5 = IR Rx

Power Supply: External. Input: 100-240 VAC, 50-60 Hz. Output: 12 VDC, 1.5 A, 18 watts

Power Consumption - Device: 3.4 watts

Power Consumption - Device and Power Supply: 4.8 watts

Remote Power Budget: 12 watts

Temperature/Humidity: Storage -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing. Operating +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling: Convection, no vents

Thermal Dissipation - Device: 10.3 BTU/hr

Thermal Dissipation - Device and Power Supply: 15.1 BTU/hr

Rack Mount: Yes, with optional 1U high rack shelf

Furniture Mount: Yes, with optional under-desk mounting kit

Enclosure Type: Metal

Enclosure Dimensions: 1.0 in H x 4.3 in W x 3.0 in D (quarter rack wide); 2.5 cm H x 10.9 cm W x 7.6 cm D. Depth excludes connectors.

Product Weight: 0.5 lbs (0.3 kg)

Regulatory Compliance: CE, c-UL, UL, C-tick, FCC Class A, ICES, VCCI. UL rated for use in plenum airspaces: meets UL 2043 for heat and smoke release, excluding the power supply. Complies with the appropriate requirements of RoHS and WEEE. CE and FCC testing is conducted with STP I/O cable.

Product Warranty: 3 years parts and labor

Everlast Power Supply Warranty: 7 years parts and labor

Diagram

Resources

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 4K 230 (dtp-dvi-4k-230_A6.pdf)

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Everlast Power Supplies

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Extron Government Solutions

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Alimentatori Everlast

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 4K 230 (dtp_dvi_230_A4_jp_ONLINE.pdf)

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 4K 230 (dtpdvi4k230_bro_A4_cn.pdf)

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 4K 230 (DTP-DVI-4K-230_BR_A4_SP_RevA5.pdf)

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Everlast 电源

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Everlast-Netzteile

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Extron-Lösungen für Behörden

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Fuentes de alimentación Everlast

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Solutions Extron pour structures gouvernementales

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Soluzioni Extron per ambienti governativi

Brochure | DTP DVI 4K 330 Tx 60-1360-12 | Sources d'alimentation Everlast

Manual | DTP DVI 4K 330 Tx 60-1360-12 | Cleaning Instruction Card

Manual | DTP DVI 4K 330 Tx 60-1360-12 | DTP Compatibility Guide

Manual | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 4K 230 Tx/Rx Setup Guide

Manual | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 4K 230 Tx/Rx User Guide

Manual | DTP DVI 4K 330 Tx 60-1360-12 | DTP互換性ガイド

Specifications | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 230 4K Tx/Rx

Panel Drawing | DTP DVI 4K 330 Tx 60-1360-12 | DTP DVI 4K 230 Tx
