Extron DTP DVI 4K 330 Rx DVI Twisted Pair Extender Receiver
- • Outputs single link DVI-D on one female DVI-I connector at the display end
- • Full 330 ft (100 m) reach at 1080p, 2560x1600 and 4K/UHD alike
- • No distance penalty for 4K, unlike shorter-reach 70 m extenders
- • Recovers stereo audio, RS-232 and IR alongside the video signal
- • Low 4.2 watt draw and only 13.0 BTU/hr thermal dissipation
- • Metal quarter-rack enclosure, 6.0 in deep, 1.0 lb (0.5 kg)
- • Powered locally or remotely across the link within a 12 watt budget
- • Backed by a 3-year Extron parts and labor warranty
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron DTP DVI 4K 330 Rx (part number 60-1360-13) — the display-end unit of Extron's DTP DVI 4K 330 extension pair, holding full 100 metre reach at every supported resolution.
What separates the 330 from its shorter-reach sibling is that the distance figure does not fall away as the picture gets bigger: 1080p, 2560x1600 and 4K/UHD all travel the same 330' (100 m) over shielded twisted pair. This receiver terminates that link, hands off single link DVI-D on one female DVI-I connector, and re-presents the stereo audio, RS-232 and infrared that rode the same cable. Transmitter and receiver are ordered separately, and either end can power the other across the link.
Key Capabilities
- Single link DVI-D output on one female DVI-I connector; DVI 1.0, HDMI 1.4 and HDCP 2.3 compliant.
- 330' (100 m) reach at 1080p 60 Hz, 2560x1600 60 Hz and 4K/UHD at 30 or 60 Hz alike.
- 300 MHz maximum pixel clock and a 10.2 Gbps ceiling, at 8, 10 or 12 bits per color.
- Balanced or unbalanced stereo output — 50 ohms unbalanced, 100 ohms balanced, greater than +11 dBu into 600 ohms.
- Serial pass-through from 300 to 115200 baud plus TTL IR from 30 kHz to 60 kHz.
- Draws 4.2 watts and can be powered remotely across the link within a 12 watt budget.
Where It Is Used
Ampronix supplies this receiver into auditoriums, multi-floor lobbies, large lecture theatres, control rooms, courtrooms and medical imaging suites — installations where the run length rules out the 70 metre class of extender and the far end still needs sound and serial control delivered on the same cable.
Specifications at a Glance
- Resolution range: 2560x1600 at 60 Hz with reduced blanking, 4096x2160 at 30 Hz, and 4K/UHD at 60 Hz when 4:2:0 chroma subsampling is used.
- Link: one female RJ-45, TIA/EIA T568B, solid 24 AWG or better STP rated at 400 MHz.
- Metal quarter-rack enclosure, 1.0 in H x 4.3 in W x 6.0 in D, 1.0 lb (0.5 kg).
- Thermal dissipation 13.0 BTU/hr; operating range +32 to +122 °F (0 to +50 °C).
- Three-year parts and labor warranty; Everlast power supply carries seven years.
Also referenced as Extron DTPDVI4K330Rx, DTP-DVI-4K-330-Rx, part number 60136013.
