Extron DTP CrossPoint 84 4K IPCP Q SA 8x4 Scaling Presentation Matrix Switcher
- • Ships with the LinkLicense user-interface upgrade included in the part number
- • 8x4 matrix switching with seamless scaling up to 4096x2160 at 30 Hz
- • IPCP Q control processor carries 2 GB SDRAM and 8 GB flash memory
- • Two scaled DTP, XTP or HDBaseT outputs plus two buffered HDMI outputs
- • Class D stereo amp delivers 50 watts per channel into 4 ohm loads
- • Four-input mic mixer with 48 V phantom power and -18 to +80 dB gain
- • 2U full-rack-width metal chassis, 3.5 x 17.4 x 15.3 in., 14 lbs
- • Signal reach to 330 ft (100 m) on shielded twisted pair in DTP 330 mode
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron DTP CrossPoint 84 4K IPCP Q SA (part number 60-1515-92A) — the 8x4 seamless scaling presentation matrix in its IPCP Q SA configuration, ordered together with the LinkLicense user-interface upgrade.
Part number 60-1515-92A covers the same 2U switcher hardware as the base IPCP Q SA build — 8 x 4 video matrix, 8 x 4 stereo audio matrix, onboard control processor and stereo power amplifier — with the LinkLicense UI entitlement bundled at the point of order. Integrators who already know the room needs an expanded user interface can specify this dash number instead of licensing the capability later.
Key Capabilities
- Ships with the LinkLicense user-interface upgrade included in the part number.
- Eight sources in, four destinations out: six HDMI inputs and two DTP or XTP twisted pair inputs.
- Two scaled DTP, XTP or HDBaseT outputs plus two buffered HDMI outputs, and two non-scaled HDMI matrix outputs.
- IPCP Q control processor with 2 GB SDRAM, 8 GB flash, an unmanaged three-port AV LAN switch, four relays and four digital I/O points.
- Four-input microphone mixer with +48 VDC phantom power and gain adjustable from -18 dB to +80 dB in 0.1 dB steps.
- Class D amplifier producing 50 watts per channel into 4 ohm loads, or 25 watts rms per channel into 8 ohms.
Where It Is Used
Training rooms, multipurpose halls, hospital education suites, distance-learning classrooms and municipal chambers where the display wall, the microphone mix and the touchpanel interface all have to be commissioned as one system rather than as separate boxes on separate networks.
Specifications at a Glance
- Video routing 8 x 4; maximum resolution 4096x2160 at 30 Hz
- Twisted pair reach up to 330 ft (100 m) in DTP 330 mode
- Audio performance: 105 dB S/N, 0.02% THD+N at 1 kHz
- Chassis 2U full rack width, 3.5 in. H x 17.4 in. W x 15.3 in. D, 14 lbs (6.4 kg)
- 136 watt consumption; 355 BTU/hr thermal dissipation
Also referenced as Extron DTPCrossPoint844KIPCPQSA, DTP-CrossPoint-84-4K-IPCP-Q-SA, part number 60151592A.
