Extron DMP 64 Plus C 6x4 ProDSP Digital Matrix Processor
- • Six independent channels of Extron acoustic echo cancellation
- • 6 mic/line inputs and 4 line outputs in a half-rack 1U chassis
- • All six inputs carry switchable +48 VDC phantom power
- • AEC tail length over 200 msec, convergence up to 60 dB/sec
- • Configurable USB audio interface: 0x8, 2x6, 4x4, 6x2 or 8x0
- • EXP port links a DTP CrossPoint or another DMP, 16 Rx and 16 Tx
- • Signal to noise better than 109 dB analog in to analog out
- • 3-year Extron parts and labor warranty
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron DMP 64 Plus C (part number 60-1823-01) — a half-rack 6x4 ProDSP digital matrix processor with six independent channels of acoustic echo cancellation.
Smaller rooms rarely need twelve inputs, but they still need real conferencing DSP. The DMP 64 Plus C answers that with six mic/line inputs, four line outputs and six AEC channels in a chassis half the width of a rack. Every one of the six main DSP channels is a FlexInput, so it can draw from a local microphone or from the expansion bus, and a configurable USB audio interface hands audio to a soft codec in 0x8, 2x6, 4x4, 6x2 or 8x0 arrangements. Eight audio file players and configurable macros round out the feature set.
Key Capabilities
- Six independent AEC channels with tail length above 200 msec and convergence up to 60 dB per second.
- Selectable noise cancellation of up to 20 dB.
- Six mono (or three stereo) mic/line inputs, all six with switchable +48 VDC phantom power.
- Four mono (or two stereo) balanced/unbalanced line outputs on two 6-pole captive screw connectors.
- Configurable USB audio interface for soft codec and computer-sourced program audio.
- EXP port links a DTP CrossPoint or another DMP with 16 channels in and 16 channels out over shielded CAT6.
Where It Is Used
Collaboration spaces, huddle rooms, small conference rooms, classrooms and consultation rooms where a full-width processor would be overkill. The half-rack metal enclosure fits on an optional 1U shelf, under a table with the mounting kit, or beside another half-rack device, and it runs on a 12 VDC external supply.
Specifications at a Glance
- Matrix: 6 mic/line inputs by 4 line outputs, 24-bit/48 kHz conversion
- AEC: 6 channels, tail length greater than 200 msec
- Signal to noise better than 109 dB analog in to analog out
- Power consumption 15.0 W device, 16.7 W with the PS 1220 supply
- Enclosure 1.7 in H x 8.7 in W x 9.5 in D, 2.35 lbs
Also referenced as Extron DMP64PlusC, DMP-64-Plus-C, part number 60182301.
