Extron AC Net AAP 70-569-03 UK White
- • UK white triple-space AAP module: one unswitched AC outlet plus RJ-45 barrel
- • 220-240 VAC, 50-60 Hz, 6 A maximum load for UK installations
- • Triple-space AAP fits standard Extron AAP mounting frames
- • Metal isolation enclosure: 1.9 in H x 1.8 in W x 3.0 in D
- • CE, RoHS and WEEE compliant. 3-year Extron warranty
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Part number 70-569-03 — UK - White
The 70-569-03 places one mains power socket rated at 220-240 V and 6 A maximum together with an RJ-45 female-to-female coupler inside a white triple-space AAP assembly. Integrators insert the metal module into standard mounting frames so that a single plate opening carries both power delivery and network pass-through, eliminating separate distribution boxes for combined connectivity.
This configuration suits AV installations that require UK-style outlets and fits optional AAP frames. It accepts 220-240 VAC at 50-60 Hz with a 6 A limit and includes a 9 ft power cord of 0.29 in outer diameter. The faceplate measures 1.39 in H x 3.50 in W while the isolation enclosure spans 1.9 in H x 1.8 in W x 3.0 in D.
