Extron 3.5 mm, 4 pole, blue, no tail (part number 101-006-01) is the four-position, tail-free captive screw connector for Extron audio, control and power terminations, supplied in tens.

Four positions sit between the common three-pole audio plug and the wider five-pole control block, and they turn up on stereo unbalanced drops, dual-pair control ports and multi-conductor power feeds. This version omits the moulded strain relief tail, which keeps the overall depth down where the block is close to a chassis wall or buried in furniture. Conductors clamp under captive screws, so the plug can be re-landed without solder or crimp tooling.

Key Capabilities

• Four positions on Extron's 3.5 mm captive screw contact pitch.
• Tail-free body for shallow enclosures and closely spaced terminal blocks.
• Clamps conductors from 16 through 28 AWG under individual screws.
• Covers stereo unbalanced audio, dual-pair control and small power feeds.
• Blue housing stays consistent with the rest of the 3.5 mm connector range.
• Ten pieces per pack for install stock and field service kits.

Where It Is Used

Meeting and training rooms, lecture theatres, wall plate and lectern interfaces, control rooms, digital signage cabinets, and medical imaging or clinical display suites - anywhere Extron switchers, interfaces and control processors expose a four-position captive screw block in a confined space.

Wiring Notes

Extron's audio connector wiring guidance calls for roughly 3/16 in (5 mm) of exposed conductor. Strip longer and neighbouring contacts can bridge; strip shorter and the wire may pull out even with the screws driven down. Leave the copper bare rather than tinned, because tinned strands lose their shape and slacken as the joint ages.

Specifications at a Glance

• Contact pitch: 3.5 mm
• Poles: 4
• Housing colour: blue
• Strain relief tail: not included
• Wire range: 16-28 AWG
• Package quantity: 10

Also referenced as Extron 3.5 mm 4 pole blue no tail, 3-5-mm-4-pole-blue-no-tail, part number 10100601.
