Teguar TP-3040-15M Panel PC
- • Teguar TP-3040-15M / TP304015M & Touchscreen Display
- • 1366 x 768 resolution at 220 cd/m2
- • Resistive touch with IP65 sealed front bezel
- • Service and repair, free evaluation
- • Part# TP-3040-15M / TP304015M, Service and Repair
This product has been discontinued by the manufacturer. Contact us for replacement options.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Teguar TP-3040-15M (TP304015M) 15.6" Panel PC & Touchscreen Display. Ampronix provides professional service and repair for the Teguar TP-3040-15M with free evaluation and fast turnaround. Both the TP-3040-15M and TP304015M model numbers are supported.
Manufacturer: Teguar, Model: TP-3040-15M, Part number: TP-3040-15M (also written TP304015M)
The Teguar TP-3040-15M (TP304015M) is a 15.6-inch all-in-one medical-grade panel PC with an integrated resistive touchscreen, built for clinical environments that need a sealed, antimicrobial computing station at the point of care.
Key capabilities
- 15.6-inch resistive touchscreen at 1366 x 768 resolution, 220 cd/m2 brightness
- IP65-rated sealed front bezel resists fluid ingress and supports hospital disinfectants
- Antimicrobial housing reduces pathogen transmission risk in clinical settings
- Active thermal cooling keeps the embedded Intel Core processor within range
- UL60601-1 and EN60601-1 certified for medical electrical safety compliance
- Panel, VESA, and wall mount options fit surgical carts, boom arms, and workstations
Where it is used
The Teguar TP-3040-15M panel PC is deployed as a bedside charting and EMR access terminal in intensive care units, as a nurse station and medication administration workstation, and as a secondary display in operating rooms and endoscopy suites where staff need glove-friendly touch access to clinical software without introducing a separate keyboard and mouse. Its sealed, antimicrobial housing also suits cleanroom and infection-control-sensitive environments.
Specifications at a glance
- Screen: 15.6-inch resistive touchscreen, 1366 x 768 resolution, 220 cd/m2
- Dimensions: 396 x 48 x 245 mm (15.6 x 1.9 x 9.6 in)
- Weight: 4.5 kg
- Power: DC 12-48V input, 120W adapter
- Ports: 4x USB 2.0, 4x serial, 1x VGA, 2x RJ45 GbE, parallel, audio
- Certifications: UL60601-1, EN60601-1, CE/FCC Class A, LVD; IP65 front bezel
Model: TP-3040-15M / TP304015M
Frequently asked questions about the Teguar TP-3040-15M
Does Ampronix offer service and repair for the Teguar TP-3040-15M Panel PC & Touchscreen Display?
Yes. Ampronix provides professional service and repair for the Teguar TP-3040-15M (TP304015M) with free evaluation and fast turnaround. Both the TP-3040-15M and TP304015M versions are covered. Call Ampronix for a quote.
Who repairs the Teguar TP-3040-15M?
Ampronix repairs the Teguar TP-3040-15M (TP304015M). Call Ampronix to start a repair quote.
How much does it cost to repair the TP-3040-15M?
The cost depends on the condition of the unit and the fault found. Call Ampronix for a free evaluation and a repair quote.
How long does TP-3040-15M repair take?
Ampronix offers fast turnaround on the TP-3040-15M. Call Ampronix for a timeline based on your unit.
Is the TP-3040-15M the same as the TP304015M?
Yes. TP-3040-15M and TP304015M are two ways of writing the same model number, and Ampronix repairs both.
What should I have ready when I request a repair for the TP-3040-15M?
Have the model number (TP-3040-15M or TP304015M), the serial number from the unit label, and a short description of the problem. Ampronix will take it from there.
What are the key features of the Teguar TP-3040-15M?
Key points for the Teguar TP-3040-15M: 15.6in Touchscreen, 1366x768 Resolution, 220 cd/m2 Brightness; Resistive Touch, IP65 Sealed Front Bezel; Antimicrobial Housing, Active Thermal Cooling; UL60601-1, EN60601-1, CE/FCC Class A Certified. Call Ampronix to confirm details for your application.
Is the Teguar TP-3040-15M a standalone monitor or a full computer?
It is an all-in-one medical panel PC: an integrated Intel Core computer and 15.6-inch resistive touchscreen in one sealed, antimicrobial enclosure, not a display alone.
