Sony FCB-EX480B SD NTSC Color Block Camera
Sony FCB-EX480B SD NTSC Color Block Camera
Sony FCB-EX480B Key Features
- • Sony FCB-EX480B / FCBEX480B NTSC color block camera
- • 1/4 type EXview HAD CCD, 470 TVL
- • 26x optical zoom with 12x digital zoom
- • Composite and Y/C output, Auto ICR
- • Sales, fast turnaround
This product has been discontinued by the manufacturer. Contact us for replacement options.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Sony FCB-EX480B (FCBEX480B) NTSC color block camera. Ampronix supplies the Sony FCB-EX480B. Both the FCB-EX480B and FCBEX480B model numbers are supported.
Manufacturer: Sony, Model: FCB-EX480B, Part number: FCB-EX480B (also written FCBEX480B)
The Sony FCB-EX480B (FCBEX480B) is a refurbished compact SD NTSC color block camera module featuring a 26x optical zoom and Sony's 1/4-type EXview HAD CCD sensor. Designed for integration into medical imaging, endoscopy, and clinical security systems, the FCB-EX480B delivers 470 TVL resolution with composite and Y/C video output. Its Auto ICR (IR Cut filter Removal) mode enables optimized day/night imaging in low-light clinical environments. Ampronix supplies and services the Sony FCB-EX480B for biomedical and imaging system integrators.
Where it is used
The Sony FCB-EX480B is integrated into medical cart cameras, endoscopy systems, clinical surveillance installations, and compact imaging heads where a self-contained zoom camera module with analog NTSC output is required. Its small size and versatile zoom range make it a common choice for OEM imaging system builders.
Specifications at a glance
- Imager: 1/4" EXview HAD CCD, Resolution: 470 TVL
- Zoom: 26x optical, 12x digital (216x total)
- Sensitivity: 0.7 lx (50 IRE), S/N ratio: >50 dB
- Outputs: Composite, Y/C, Format: NTSC
- Dimensions: 52 × 57.5 × 88.5 mm, Weight: 230 g
- Power: 1.6 W (idle) / 2.5 W (active)
- Part number: FCB-EX480B / FCBEX480B
Model: FCB-EX480B / FCBEX480B
Related: Medical Cameras, Sony products.
Frequently asked questions about the Sony FCB-EX480B
Is the Sony FCB-EX480B available?
Yes. Ampronix supplies the Sony FCB-EX480B (FCBEX480B), subject to availability. Both the FCB-EX480B and FCBEX480B versions are covered. Call Ampronix for current availability and a quote.
Where can I buy the Sony FCB-EX480B?
Ampronix sells the Sony FCB-EX480B (FCBEX480B) and ships to medical facilities. Call Ampronix for pricing and lead time.
What should I have ready when I request a quote for the FCB-EX480B?
Have the model number (FCB-EX480B or FCBEX480B) and the quantity you need. Ampronix will confirm availability and pricing.
What are the key features of the Sony FCB-EX480B?
Key points for the Sony FCB-EX480B: 1/4 type EXview HAD CCD, 470 TVL; 26x optical zoom with 12x digital zoom; Composite and Y/C output, Auto ICR. Call Ampronix to confirm details for your application.
FCB-EX480B vs FCB-EX780B, what is the difference?
, Both are compact NTSC block cameras with 26x zoom, but the FCB-EX780B uses a 1/6-type Super HAD CCD with different low-light characteristics. The FCB-EX480B is generally the preferred choice for medical imaging integrations requiring EXview HAD sensitivity.
