Ampronix provides industry-leading service and repair for the Karl Storz Image 1 HD 222010-20 SCB Video Console, also known as the:

Image 1 HD Hub (Model 222010-20)
Image 1 HD SCB Camera Console (222010-20)
Image 1 HD Video Processor (222010-20)
Image 1 HD CCU (Camera Control Unit)
Image One Hub HD 222010-20

This system is the central hub of the Karl Storz Image 1 HD surgical imaging platform, responsible for camera head signal processing, image output, and communication with light sources and monitors.

When a Karl Storz Image 1 HD / Image One Hub HD 222010-20 unit develops issues such as no video output, power supply failure, fan errors, or SCB communication faults, Ampronix performs a full OEM-level diagnostic and repair service.

Each repaired Image 1 HD camera console is calibrated, signal-tested, and verified for HD output integrity using compatible Karl Storz camera heads. Our specialized testing process ensures restored performance and reliability in operating room environments.

Ampronix Service & Support Highlights
Complete diagnostics and component-level repair for 222010-20 SCB consoles
Main board, image board, and power supply repair
I/O port and connector replacement (HD-SDI, DVI, SCB)
Camera head communication testing and recalibration
Fan, cooling, and power regulation maintenance
Free evaluation and detailed repair estimate before service

Technical Information
Model: Karl Storz Image 1 HD SCB 222010-20
Alternate References: Image One Hub HD 222010-20, Image 1 HD Video Processor, Image 1 HD CCU
Manufacturer: Karl Storz GmbH & Co. KG
Power Requirements: 100–240 VAC, 50/60 Hz
Connectivity: DVI-I, HD-SDI, SCB communication port
Form Factor: Rack-mountable video processor console
Typical Weight: Approx. 9.5 kg (21 lbs)
Compatible Accessories: Karl Storz camera heads (2222010 series), light sources, and HD monitors
