Details

5MP Monochrome JVC MS-S500 comes with 1,000 cd/m² calibration to make it the best solution for breast image diagnosis. With a maximum luminance of 3000 cd/m², a long lifetime is secured even in this preset. The brighter screen dramatically increases the number of perceptual grayscale steps to improve visibility of microcalcifications, tumors and structures.

Model: MS-S500BG, Part Number: MS-S500BGOUA, 5MP 21.3" Monochrome for Mammo and Tomo

Model: MS-S500 Dualstand, 5MP 21.3" Dual Displays Monochrome with desk dualstand.

Specifications

Manufacturer: JVC

Condition: New

Modality: Mammography

Accessories: Power cord x2, DVI cable x2, DisplayPort cable x2, USB cable x2, Operation manual, Installation manual, Software (QA Medivisor Agent LE)

Certifications: ANSI/AAMI ES60601-1 (2005) + A1 (2012), CAN/CSA-C22.2 No. 60601-1 (2014), CE (EN60601-1, EN60601-1-2), RCM, FCC Part15 subpart B Class B, ICES-003-B, VCCI-B, J-Moss, RoHS

Contrast Ratio: 2000:1 (typ.)

GTIN: 046838079979

Mounting Options: VESA standard (100 mm x 100 mm)

Pixel Pitch: 0.165 mm x 0.165 mm

Power Consumption: 80W (typ.)

Power Input: 100V - 240 V 50/60 Hz

Resolution: 2048 x 2560 (Independent Sub-pixel Drive technology ON : 2048 x 7680)

Screen Size: 21.3-inch

Screen Technology: monochrome TFT, IPS technology

Video Inputs: DVI-D (DVI 1.0 compliant), DisplayPort (DisplayPort 1.2a compliant)

Viewing Angle: 178° vertical and horizontal

Warranty: 5 Years

Resources

• JVC-MSS500-Brochure-EN.pdf

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

JVC MS-S500 5MP Mammo Diagnostic Radiology Monitor

Name: JVC MS-S500 5MP Mammo Diagnostic Radiology Monitor
Brand: JVC
SKU: JVC-MSS500
Availability: InStock

Manufacturer: JVC

Type: Mammography & Tomosynthesis Displays

JVC MS-S500 Mammography 5MP Monochrome Monitor Display

• Super High bright & High contrast image quality for Breast image diagnosis
• Improved Diagnostic Visibility
• Independent Sub-pixel Drive Technology
• Improved Diagnostic Visibility
• Integrated QA Solution
