Extron XTP DTP 24/75 (part number 26-702-75) — a 75' (22.8 m) precision-terminated shielded twisted pair assembly for Extron XTP and DTP systems.

Seventy-five feet takes an XTP or DTP link across a building, and it still sits comfortably under the 175-foot ceiling Extron places on DTP3 uncompressed 4K/60 at 4:4:4 over XTP DTP 24 cable. The bulk cable is certified to 475 MHz at up to 330 feet (100 m) and has been tested independently against HDBaseT Alliance requirements. Extron terminates both ends with XTP DTP 24 Plugs and molded strain reliefs, keeping the braid and foil shield continuous through the connector.

Key Capabilities

• Bandwidth certified to 475 MHz at distances up to 330' (100 m)
• DTP3 uncompressed 4K/60 at 4:4:4 supported out to 175' (53 m)
• SF/UTP construction: four 24 AWG twisted pairs in a braid and foil shield
• Factory-terminated with Extron XTP DTP 24 Plugs and molded strain reliefs
• Independently tested against HDBaseT Alliance performance requirements
• Exceeds HDMI error rate specification of under one pixel per billion at 100 m

Where It Is Used

Auditoriums and houses of worship with a projection position at the rear, campus teaching spaces served from a central rack room, command centres feeding distant video walls, and multi-room installations sharing a single head end.

Specifications at a Glance

• Cable length: 75' (22.8 m)
• Bandwidth: certified to 475 MHz to 330' (100 m)
• Cable: SF/UTP, four 24 AWG twisted pairs, overall braid and foil shield
• Connectors: Extron XTP DTP 24 Plugs, factory-terminated
• Re-terminable with the Extron CTU 45 Universal RJ-45 Termination Tool

Also referenced as Extron XTPDTP2475, XTP-DTP-24-75, part number 2670275.
