Extron XTP DTP 24/200 (part number 26-702-200) — a 200' (61.0 m) precision-terminated shielded twisted pair assembly for Extron XTP and DTP systems, retired by Extron.

Two hundred feet is a whole-building run delivered as a single finished part, which is why it appeared in venues where a field splice was unacceptable. Worth knowing before you specify it: Extron states DTP3 uncompressed 4K/60 at 4:4:4 over XTP DTP 24 cable only out to 175 feet (53 m), so at this length the assembly is intended for DTP2, DTP, XTP II and XTP. The cable itself remains certified to 475 MHz at distances up to 330 feet (100 m), with four 24 AWG twisted pairs inside an overall braid and foil shield.

Key Capabilities

• Bandwidth certified to 475 MHz at distances up to 330' (100 m)
• Supports DTP2, DTP, XTP II and XTP at this length
• SF/UTP construction: four 24 AWG twisted pairs in a braid and foil shield
• Factory-terminated with Extron XTP DTP 24 Plugs and molded strain reliefs
• Independently tested against HDBaseT Alliance performance requirements
• Exceeds HDMI error rate specification of under one pixel per billion at 100 m

Where It Is Used

Arenas, convention centres and large houses of worship, stadium and transport-hub signage runs, multi-building campus links, and maintenance of legacy XTP or DTP infrastructure built around this length.

Specifications at a Glance

• Cable length: 200' (61.0 m)
• Bandwidth: certified to 475 MHz to 330' (100 m)
• Cable: SF/UTP, four 24 AWG twisted pairs, overall braid and foil shield
• DTP3 4K/60 4:4:4 is specified to 175' (53 m) on XTP DTP 24 cable
• Status: retired by Extron

Also referenced as Extron XTPDTP24200, XTP-DTP-24-200, part number 26702200.
