Extron XTP DTP 22/150 (part number 26-739-150) — a 150 ft (45.7 m) precision-terminated shielded twisted pair cable for XTP and DTP infrastructure.

By 150 feet, cable choice decides whether a 4K/60 link works at all. Extron's answer is a dedicated 22 AWG design rather than a repurposed network cable: solid bare copper conductors in four pairs, each foil-shielded, bundled inside a tinned copper braid and finished with gray PVC. The whole assembly is certified to 500 MHz and cleared for DTP3 uncompressed 4K/60 at 4:4:4 out to 330 ft, which is why Extron names it as the recommended cable for optimal DTP3 performance.

Key Capabilities

• Bandwidth certified to 500 MHz at distances up to 330 ft (100 m).
• Carries DTP3 uncompressed 4K/60 video at 4:4:4 across the run.
• Maintains signal integrity for uncompressed HDMI 2.0b.
• Four individually shielded 22 AWG pairs inside an overall braid.
• Shielded CAT6A RJ45 male plugs with gold-plated contacts.
• Cleared for DTP3, DTP2, DTP, XTP II and XTP systems.
• Molded strain relief protects the connector-sleeve stress point.

Where It Is Used

Common in campus buildings, large houses of worship, sports facilities and hospitals where a single pull has to reach a distant endpoint, and where re-pulling later would mean opening ceilings that are already closed.

Specifications at a Glance

• Length: 150 ft (45.7 m)
• Shielding: S/FTP, AL foil per pair plus tinned copper braid
• Connector: 1 male shielded CAT6A RJ45 to 1 male shielded CAT6A RJ45
• Cable rating: non-plenum, NEC CM-rated
• Regulatory: NEC 800, CM UL 1685, RoHS, WEEE

Also referenced as Extron XTPDTP22150, XTP-DTP-22-150, part number 26739150.
