Details

Extron VLS 3002H (part number 42-347-03) — a complete VoiceLift Pro classroom voice amplification system with one pendant microphone, one handheld microphone and ZipClip 400 mounting.

The pendant stays with the instructor; the handheld goes to whoever is speaking next. That combination suits question-and-answer teaching, guest speakers and any lesson where a student needs to be heard at the back of the room. Both microphones use the same 1900 MHz digital link to the VLR 302 receiver, and the PVCA 452 controller amplifier mixes them before driving the ceiling speakers.

Key Capabilities

One VLP 302 pendant plus one VLH 302 handheld microphone
Handheld measures 8.0 in tall with a 1.8 in maximum diameter, 5.0 oz with battery
Rated for a 40 x 40 ft room, 1600 sq ft (148.6 sq m) minimum reception area
PVCA 452 amplifier gives 25 watts per channel into 4 or 8 ohms at 1% THD
FF 120 Flat Field speakers spread sound across 170 degrees of conical coverage
Both microphones run on a single AA cell for at least 8 hours
ZipClip 400 and ZipCaddy 400 hardware mounts the electronics behind a flat panel

Where It Is Used

Discussion-led classrooms, lecture and seminar rooms, assembly and multipurpose spaces, and training rooms where a passed microphone is part of the format. Widely used in schools, colleges and corporate learning environments.

Specifications at a Glance

Microphones: one VLP 302 pendant, one VLH 302 handheld
Amplifier: PVCA 452, 25 W per channel, 4/8 ohms, 20 Hz to 20 kHz
Radio: 1900 MHz, 40 x 40 ft minimum coverage
Mounting: ZipClip 400 with ZipCaddy 400
Warranty: 3 years parts and labor; 90 days on the microphone battery

Also referenced as Extron VLS3002H, VLS-3002H, part number 4234703.

Specifications

Part Number: 42-347-03

Manufacturer: Extron

Model: VLS 3002H

Condition: New

Configuration: Pendant and Handheld VoiceLift System - ZipClip

Included Components: VLP 302 pendant microphone, VLH 302 handheld microphone, VLR 302 receiver, VLC 302 charging station, PVCA 452 controller amplifier, FF 120 Flat Field speakers (pair), ZipClip 400 mounting

Operating Range: 40' x 40' minimum coverage

Reception Area: 1600 square feet (148.6 square meters) minimum

Radio Frequency: 1900 MHz

Amplifier Output Power: 25 watts per channel, 4/8 ohms, 1 kHz, 1% THD

Amplifier Load Impedance: 4/8 ohms, single channel or stereo

Frequency Response: 20 Hz to 20 kHz, +1 dB / -3 dB at 1 watt output, 8 ohm load

THD + Noise: 0.1%, 1 kHz, 3 dB below clipping

Signal to Noise: Greater than 90 dB, 20 Hz to 20 kHz at maximum output (unweighted), 8 ohms

Damping Factor: Greater than 75 at 8 ohms

Crosstalk: Less than -85 dB at 1 kHz

Stereo Channel Separation: Greater than 80 dB at 1 kHz

PVCA 452 Control: 1 bidirectional RS-232; 1 front panel female USB type-C (USB 2.0, high speed); paging sensor on a 3.5 mm captive screw connector, 3 pole

PVCA 452 Software: Extron Global Configurator Plus and Professional for Windows

PVCA 452 Power Supply: External; input 100-240 VAC, 50-60 Hz; output 12 VDC, 4.2 A, 50 watts

PVCA 452 Power Consumption: Device 18.16 watts; device and power supply 20.55 watts

PVCA 452 Enclosure: Metal; 1.00 in H x 13.1 in W x 3.5 in D (2.5 x 33.3 x 8.9 cm)

PVCA 452 Operating Temperature: +32 to +122 F (0 to +50 C), 10% to 90% noncondensing; convection cooled, no vents

VLP 302 Pendant Microphone: 1 mono via integrated MEMS microphones plus 1 mono unbalanced auxiliary mic input on a 3.5 mm jack; power, volume and function controls; 3.0 in H x 1.47 in W x 1.2 in D (7.6 x 3.7 x 3.0 cm); 2.2 oz (62 g) with battery

VLH 302 Handheld Microphone: 1 mono via integrated MEMS microphones plus 1 stereo unbalanced auxiliary line level input on a 3.5 mm jack; power, volume and link controls; 8.0 in H x 1.8 in maximum diameter (20.2 x 4.6 cm); 5.0 oz (142 g) with battery

Microphone Battery: 1 AA size NiMH or alkaline; minimum 8 hours continuous use; about 5 hours to recharge a 2400 mAh NiMH cell

VLR 302 Receiver: Rack, ceiling or wall mountable; 2 normally open relays; 1 RS-232 port via RJ-45 (38400 baud, 8 data bits, 1 stop bit, no parity); 1 USB; 12 VDC, 0.2 A; 1.66 in H x 2.15 in W x 4.50 in D (4.2 x 5.5 x 11.4 cm); 0.25 lbs (0.11 kg)

VLC 302 Charging Station: External supply 110 to 130 VAC, 50-60 Hz to 5 VDC, 2.6 A regulated via USB Micro B; 5 VDC, 0.5 A; 1.5 in H x 4.4 in W x 3.4 in D (3.9 x 11.3 x 8.6 cm); 0.66 lbs (0.3 kg)

FF 120 Flat Field Speakers: 16 W (rms) continuous pink noise, 32 W (rms) continuous program; 170 degree conical coverage; 8 ohms per speaker; drops into a 2' x 2' or 2' x 4' suspended tile; 3.25 in H x 23.75 in W x 11.75 in D; 4.7 lbs (2.1 kg) each

Mounting Kit: ZipClip 400 and ZipCaddy 400; rack rail mount with required hardware, furniture mount with included hardware; ZipClip 400 9.5 in H x 4.6 in W x 0.6 in D (241 x 116 x 15 mm); ZipCaddy 400 8.6 in H x 4.4 in W x 0.4 in D (218 x 111 x 10 mm); load 9.5 lbs (4.3 kg) vertical, 5.0 lbs (2.27 kg) horizontal; high impact plastic

Regulatory Compliance: EMI/EMC: CE, FCC Class B; complies with the appropriate requirements of RoHS and WEEE

Vibration: ISTA 1A in carton (International Safe Transit Association)

Warranty: 3 years parts and labor; microphone battery 90 days
