Extron VLM 3002H VoiceLift Pro Wireless Microphone Kit 42-255-03
Extron VLM 3002H VoiceLift Pro Wireless Microphone Kit 42-255-03
Extron VLM 3002H VoiceLift Pro Wireless Microphone Kit
- • Pendant and handheld VoiceLift Pro microphone kit for Extron systems
- • VLH 302 handheld: 8.0 in tall, 1.8 in max diameter, 5.0 oz with battery
- • 1900 MHz digital RF link - no line of sight needed, unlike infrared
- • Covers a 40 x 40 ft room, 1600 sq ft minimum reception area
- • Both microphones run at least 8 hours of continuous use on one AA cell
- • VLC 302 charging station takes either microphone in either bay
- • Handheld auxiliary jack accepts an unbalanced stereo media player
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron VLM 3002H (part number 42-255-03) — the pendant and handheld VoiceLift Pro wireless microphone kit for Extron classroom AV systems, US and Canada version.
Pairing a worn pendant with a passed handheld is the arrangement most teachers end up wanting once they have used voice reinforcement for a term. The instructor keeps the VLP 302 around their neck; the VLH 302 goes to a student, a guest speaker or a second presenter. Both link to the same VLR 302 receiver, which feeds the classroom switcher over one RJ-45 cable and needs no separate power supply.
Key Capabilities
- One VLP 302 pendant and one VLH 302 handheld on a single receiver
- Handheld is 8.0 in (20.2 cm) long and 5.0 oz (142 g) with its battery
- 1900 MHz digital RF link — no line of sight needed, unlike infrared
- Rated for a 40 x 40 ft room, 1600 sq ft (148.6 sq m) minimum reception area
- Both microphones run at least 8 hours of continuous use on one AA cell
- VLC 302 charging station docks either microphone in either bay
- Handheld auxiliary jack accepts an unbalanced stereo media player
Where It Is Used
Question-and-answer teaching, student presentations, guest lectures and assemblies in rooms that already have Extron classroom AV switching. Common in schools, colleges, corporate training suites and clinical education spaces.
Specifications at a Glance
- Kit contents: VLP 302 pendant, VLH 302 handheld, VLR 302 receiver, VLC 302 charger, 3 ft CATx STP cable
- Radio: 1900 MHz, 40 x 40 ft minimum coverage
- Handheld: 8.0 in H x 1.8 in maximum diameter (20.2 x 4.6 cm)
- Receiver: 12 VDC at 0.2 A, 0.25 lbs (0.11 kg)
- Warranty: 3 years parts and labor; 90 days on the microphone battery
Also referenced as Extron VLM3002H, VLM-3002H, part number 4225503.
