Extron VGA-A M-M MD/3 VGA and Audio Cable
- • Extron VGA-A M-M MD/3 molded VGA and audio cable 3 ft
- • Molded 15-pin HD male ends with 3.5 mm stereo leads
- • Audio leads 24 in and 8 in, foil shielded body
- • Sales, replacement and exchange
- • Part# 26-490-01 / 2649001
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron VGA-A M-M MD/3 (part number 26-490-01) - a 3' (90 cm) male-to-male VGA cable with an analogue stereo audio lead bonded to the same assembly.
Running video and audio as two separate cables doubles the dressing work and doubles the chance one of them gets unplugged. This assembly solves that by pairing Extron MHRVGA cable, terminated in molded 15-pin HD male connectors, with a stereo mini plug lead at each end. The audio pigtails are deliberately different lengths - 24 inches at one end and 8 inches at the other - so the long tail reaches a laptop headphone jack while the short tail lands neatly beside the switcher input.
Key Capabilities
- Carries computer video, analogue stereo audio and ID bit signals in one 3' (90 cm) assembly
- Pin 9 +5 VDC and the ID bits travel end to end when the graphics card meets VESA DDC version 3
- Molded 15-pin HD male connectors plus 3.5 mm stereo mini plugs
- Audio lead measures 24 inches on one end and 8 inches on the other
- VGA shell tied to ground for ESD protection
- Injection-molded body with an overall foil shield for EMI isolation
Where It Is Used
Inside Cable Cubby, AVEdge and HSA enclosures where a presenter needs both signals from one lead, lectern interiors, rack tie-lines to an audio-capable switcher, and huddle tables where the source sits within arm's reach of the plate.
Specifications at a Glance
- Cable length: 3' (90 cm)
- Connectors: 2 male 15-pin HD molded, each with a 3.5 mm stereo mini plug lead
- Cable: Extron MHRVGA
- Audio pigtails: 24 in and 8 in
- Status: retired by Extron
Frequently asked questions about the Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable
Does Ampronix sell the Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable?
Yes. Ampronix is an authorized Extron distributor and sells the Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable (26-490-01). Call Ampronix for a quote.
Does Ampronix offer replacement and exchange for the Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable?
Yes. Ampronix provides sales, replacement and exchange for the Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable. Call Ampronix for a quote.
Is the Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable listed under other names?
Yes. The Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable is also referenced as Extron VGAAMMMD3, VGA-A-M-M-MD-3, part number 2649001.
What are the key features of the Extron VGA-A M-M MD/3 3 ft VGA & Audio Molded Cable?
Key points: Carries computer video, analogue stereo audio and ID bit signals in one 3' (90 cm) assembly; Pin 9 +5 VDC and the ID bits travel end to end when the graphics card meets VESA DDC version 3; Molded 15-pin HD male connectors plus 3.5 mm stereo mini plugs; Audio lead measures 24 inches on one end and 8 inches on the other. Call Ampronix to confirm details for your application.
Also referenced as Extron VGAAMMMD3, VGA-A-M-M-MD-3, part number 2649001.
