Extron USBC Pro/30 (part number 26-741-30) — the longest cable in the USBC Pro Series at 30 ft (9.1 m), carrying 4K/30 video, 5 Gbps USB data and 60 W power delivery.

Thirty feet is the full reach of the series, and the hybrid optical-copper construction is what makes it viable. Video crosses the distance as light on two DisplayPort lanes; power and the USB 2 path stay on copper. Built-in active circuitry is fed by whichever connected device has power available, so there is no supply to mount and no chassis to cool. For anyone specifying a room where the source position is fixed and far from the screen, this replaces a whole extension system with one cable.

Key Capabilities

• Longest reach in the series at 30 ft (9.1 m) with no external power supply.
• Two-lane DisplayPort Alt Mode 1.4 at HBR3, 16.2 Gbps of video bandwidth.
• Video up to 4096x2160 at 30 Hz with 4:4:4 chroma and 12-bit colour.
• SuperSpeed USB 3.2 Gen 1 data at up to 5 Gbps.
• Bidirectional USB Power Delivery to 60 W.
• 0.26 in (6.5 mm) diameter, 0.79 in (20 mm) bend radius, 111 N pull strength.
• RoHS, WEEE, CE and UL-CMX compliant.

Where It Is Used

Large meeting rooms and boardrooms, auditorium lecterns feeding distant projectors, classroom teaching walls, digital signage installations, and broadcast, simulation or clinical environments where the operator position and the display are well separated.

Specifications at a Glance

• Length: 30 ft (9.1 m)
• Video: up to 4096x2160 at 30 Hz, DisplayPort 1.4, HDCP 2.3
• USB: 3.2 Gen 1 at up to 5 Gbps
• Power delivery: up to 60 W, bidirectional
• Cable: 0.26 in (6.5 mm) diameter, USB-C male to USB-C male

Also referenced as Extron USBCPro30, USBC-Pro-30, part number 2674130.
