Extron USBC-DPF/0.5 (part number 26-719-01) — a 6 in (15 cm) USB-C male to DisplayPort female adapter pigtail for DisplayPort Alt Mode sources.

Where a room is wired for DisplayPort but the laptops arriving in it have only USB-C, this short tail solves the problem without changing the infrastructure. The USB-C plug goes into the source and the DisplayPort socket accepts the existing permanent cable, so only this six-inch piece has to be swapped as devices change. Extron builds it on a very slim 0.17 in jacket, which matters inside a cable retractor or a crowded floor box.

Key Capabilities

• Converts DisplayPort Alt Mode from a USB-C port to a standard DisplayPort connection.
• DisplayPort 1.1a over one, two or four lanes, up to DisplayPort 1.1a and HDCP 1.3.
• Maximum video data rate of 8.91 Gbps, 2.7 Gbps per lane.
• Resolutions to 4096x2160 and 3840x2160 at 30 Hz with 4:4:4 chroma and 8-bit colour.
• Passes EDID information from the display back to the source.
• Very slim 0.17 in (4.2 mm) jacket over multi-mode fibre and 34 AWG copper.
• Gold-plated contacts and Extron Limited Lifetime Performance warranty.

Where It Is Used

Conference table boxes and cable retractors, lectern connectivity panels, hot-desk positions, and control or design workstations where the fixed DisplayPort cabling has to keep accepting new USB-C laptops.

Specifications at a Glance

• Length: 6 in (15 cm)
• Video: up to 4K at 30 Hz, DisplayPort 1.1a, HDCP 1.3
• Maximum data rate: 8.91 Gbps (2.7 Gbps per lane)
• Connectors: 1 USB-C male to 1 DisplayPort female
• Cable: 0.17 in (4.2 mm) diameter, 1.70 in (43 mm) bend radius

Also referenced as Extron USBCDPF05, USBC-DPF-0-5, part number 2671901.
