Extron UCM R308 Universal Controller Mounting Panel
- • 3U, full rack width panel for standard 19 inch equipment racks
- • Accepts 3-gang products such as the MLC 226 IP and MLC Plus 200
- • Openings for up to 8 single-space AAP AV Connectivity Modules
- • Also holds up to three decorator-style wallplates
- • Optional UCM 100 mount adds Flex55 and EU module support
- • Black powder coated steel panel, 5.2 in H x 19.0 in W x 0.5 in D
- • Light in the rack at just 1.4 lbs (0.6 kg)
- • Backed by a 3-year Extron parts and labor warranty
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron UCM R308 (part number 60-1166-02) — a 3U, full-rack-width universal controller mounting panel with eight AV connectivity module openings.
Control panels designed for walls do not naturally belong in a rack, and improvised brackets rarely survive an inspection. The UCM R308 gives them a proper home: a 19 inch, black powder coated steel panel that accepts a three-gang product in the centre — an MLC 226 IP MediaLink controller, an MLC Plus 200 MediaLink Plus controller, a TLP 350MV touchpanel, or up to three decorator-style wallplates such as the MLC 62 RS D. Around that centre section sit openings for eight single-space AAP AV Connectivity Modules, so power, VGA, HDMI, DVI, XLR and cable pass-through plates can all terminate on the same 3U face. Every controller, wallplate and AAP module is ordered separately.
Key Capabilities
- 3U, full rack width panel for 19 inch equipment racks
- Accepts three-gang products including the MLC 226 IP and MLC Plus 200
- Alternatively carries up to three decorator-style wallplates
- Openings for up to eight single-space AAP AV Connectivity Modules
- The optional UCM 100 Universal Control Mount adds Flex55 and EU module support
- Black powder coated steel construction, 1.4 lbs (0.6 kg)
Where It Is Used
Equipment racks in classrooms, lecture theatres, control rooms and command centres where operators need physical buttons at the rack rather than only on a wall. It is also a tidy way to bring rack-front connectivity and a control interface onto one panel in mobile racks and credenza builds.
Specifications at a Glance
- Enclosure dimensions: 5.2 in H x 19.0 in W x 0.5 in D (13.3 cm H x 48.3 cm W)
- Enclosure type: metal, black powder coat finish
- Product weight: 1.4 lbs (0.6 kg); shipping weight 2 lbs (1 kg)
- Vibration: ISTA 1A in carton
- Warranty: 3 years parts and labor
Extron lists this panel as a MediaLink controller accessory; the MLM 100 D mounting kit is a related option for wall-mounted button panels.
Also referenced as Extron UCMR308, UCM-R308, part number 60116602.
