Extron TLP Pro 725C 60-1564-12

Extron TLP Pro 725C 7" PoE Cable Cubby Touchpanel 60-1564-12

Extron TLP Pro 725C 7" PoE Cable Cubby Touchpanel 60-1564-12

Manufacturer: Extron

Type: TouchLink Pro Touchpanels

Extron TLP Pro 725C Cable Cubby Touchpanel

  • • 7" Gorilla Glass touchscreen at 420 nits, 700:1 contrast
  • • Metal cable cubby enclosure accepts AC, AAP, and retractor modules
  • • Single-cable PoE (802.3af Class 3) power and Ethernet control
  • • Open/closed lid switch reports enclosure state to the system
  • • Motion and light sensors dim the display automatically
  • • 3-year parts and labor warranty; 1-year on display/overlay

Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!

SKU: EXTRON-TLPPRO725C-60156412

Details

Extron TLP Pro 725C (part number 60-1564-12) — a black 7" PoE touchpanel built into a furniture-mount cable cubby enclosure.

Like its 60-1564-02 sibling, this unit combines a capacitive touchscreen with a cable-management box in one furniture cutout, shipping without an AC power module installed. The metal enclosure accepts AC modules, AAP connectivity modules, retractor units, and AV cables alongside the panel. A quad-core processor with 2 GB RAM and 8 GB storage handles the interface, and an open/closed lid switch reports enclosure state back to the control system.

Key Capabilities

  • 7" capacitive touchscreen with Gorilla Glass at 420 nits, 700:1 contrast
  • Metal cable cubby enclosure accepts AC, AAP, and retractor modules
  • Single-cable PoE (802.3af Class 3) for power and Ethernet control
  • Open/closed lid switch reports enclosure state to the system
  • Motion and light sensors dim the display automatically
  • 3-year parts and labor warranty (1 year on display and overlay)

Where It Is Used

The combined touchpanel and cable cubby fits conference tables and lecterns where control and guest cable connections need to share a single furniture cutout, in boardrooms, classrooms, and training rooms.

Specifications at a Glance

  • 7" WSVGA capacitive touchscreen, 24-bit color
  • PoE powered, 8.6 W device draw
  • 2 GB RAM / 8 GB storage
  • Metal enclosure, 5.85 lbs, without AC module

Also referenced as Extron TLPPRO725C, TLP-Pro-725C, part number 60156412.
