Extron SYM BNCF/100 (part number 26-531-07) — at 100 ft (30.4 m) this is the longest assembly Extron lists in the SYM BNCF Series.

Over a hundred feet, an RGBHV path lives or dies on how consistent the five legs are. A factory-built MHR-5 assembly, part 22-020-03, removes the variables: identical cable, identical length, identical shielding, and BNCs terminated on production tooling rather than in a ceiling void. The cable is smaller and more flexible than the equivalent in standard 75 ohm coax, so the pull is realistic, and the moulded VGA male shell is grounded for ESD protection under an overall foil shield. NEC CM rated.

Key Capabilities

• 100 ft (30.4 m): the longest length in the SYM BNCF Series
• Five matched, colour-coded 75 ohm female BNC legs
• Extron MHR-5 cable, part number 22-020-03
• Male 15-pin HD terminates directly on the source or display
• Grounded VGA shell with an overall foil shield
• NEC CM rated cable

Where It Is Used

Building-scale analogue video: a central equipment room feeding auditorium projectors or arena displays, broadcast and production patch fields, and command centres where the source rack and the display wall are on different floors.

Specifications at a Glance

• Length: 100 ft (30.4 m), measured tip-to-tip including connectors
• Connectors: one male 15-pin HD, five female 75 ohm BNC
• Cable: Extron MHR-5, part number 22-020-03
• Rating: NEC CM

Also referenced as Extron SYMBNCF/100, SYM-BNCF-100, part number 2653107.
