Extron SYM BNCF/1 (part number 26-531-11) — a 1 ft (30 cm) assembly with a moulded 15-pin HD male at one end and five colour-coded 75 ohm BNC females at the other.

One foot gives just enough cable to route around a bracket or reach across a patch panel without leaving slack to tie back. Because the VGA end is male, the assembly mounts straight onto a source or display port; the five BNC females then accept individual coaxial jumpers on the RGBHV side. Extron builds all five legs from MHR-5 cable, part 22-020-03, so each is a true 75 ohm path. The moulded shell is grounded against ESD and foil shielded against EMI, on NEC CM rated cable.

Key Capabilities

• 1 ft (30 cm) VGA male to five BNC female assembly
• Five colour-coded 75 ohm female BNC connectors
• Extron MHR-5 cable, part number 22-020-03
• Grounded VGA shell for electrostatic discharge protection
• Injection moulded with an overall foil shield
• NEC CM rated cable

Where It Is Used

Patch panels and rack bays in control rooms, broadcast facilities and teaching spaces where a VGA-terminated source has to be presented as five separate BNC connections for onward routing.

Specifications at a Glance

• Length: 1 ft (30 cm)
• Connectors: one male 15-pin HD, five female 75 ohm BNC
• Cable: Extron MHR-5, part number 22-020-03
• Rating: NEC CM

Also referenced as Extron SYMBNCF/1, SYM-BNCF-1, part number 2653111.
