Extron SYF BNCF/50 (part number 26-532-05) — a 50 ft (15.2 m) VGA female to five-BNC-female assembly for cross-building analogue video.

Fifty feet is an infrastructure run, and the five legs have to behave as one cable to be worth installing. Extron's MHR-5 assembly, part 22-020-03, delivers exactly that: five matched 75 ohm coaxial paths, colour coded and terminated in female BNCs, inside a jacket that is thinner and more flexible than regular coax and therefore actually pullable over that distance. The moulded VGA female shell is grounded for ESD protection with an overall foil shield beneath the moulding, and the cable carries an NEC CL2 rating.

Key Capabilities

• 50 ft (15.2 m) VGA female to five BNC female run
• Five matched 75 ohm coaxial legs, individually colour coded
• Extron MHR-5 cable, part number 22-020-03
• Easier to pull through conduit than five discrete coax runs
• Grounded VGA shell plus an overall foil shield
• NEC CL2 rated cable

Where It Is Used

Equipment room to auditorium projector feeds, control room patch fields, and campus AV where legacy RGBHV switching has to meet VGA-terminated sources or displays at the far end of a building.

Specifications at a Glance

• Length: 50 ft (15.2 m), measured tip-to-tip including connectors
• Connectors: one female 15-pin HD, five female 75 ohm BNC
• Cable: Extron MHR-5, part number 22-020-03
• Rating: NEC CL2

Also referenced as Extron SYFBNCF/50, SYF-BNCF-50, part number 2653205.
