Extron SYF BNCF/1 (part number 26-532-11) — a 1 ft (30 cm) assembly with a 15-pin HD female at one end and five colour-coded 75 ohm BNC females at the other.

A foot is the working length for a patch inside a rack bay or behind a connector plate: long enough to route around a bracket, short enough that nothing has to be coiled. The five legs are Extron MHR-5 cable, part 22-020-03, so each is a genuine 75 ohm coaxial path rather than a bundle of hookup wire, and the colour coding maps directly onto the red, green, blue and sync convention an installer already uses. The moulded VGA shell is grounded against ESD and foil shielded against EMI, on NEC CL2 rated cable.

Key Capabilities

• 1 ft (30 cm) VGA female to five BNC female assembly
• Five colour-coded 75 ohm BNC female connectors
• Built on Extron MHR-5 cable, part number 22-020-03
• Grounded VGA shell for ESD protection
• Injection moulded with an overall foil shield
• NEC CL2 rated

Where It Is Used

Rack bays and connector plates in control rooms, broadcast facilities and classrooms where a VGA-terminated device meets an RGBHV patch field, and in test positions where a source has to be dropped onto individual BNC inputs quickly.

Specifications at a Glance

• Length: 1 ft (30 cm)
• Connectors: one female 15-pin HD, five female 75 ohm BNC
• Cable: Extron MHR-5, part number 22-020-03
• Rating: NEC CL2

Also referenced as Extron SYFBNCF/1, SYF-BNCF-1, part number 2653211.
