Extron SYF BNCF/0.5 (part number 26-532-01) - a 6 in (15 cm) breakout that turns one 15-pin HD female connector into five colour-coded 75 ohm BNC females.

This is a panel adapter more than a cable. Six inches is just enough to get from a VGA-terminated wall plate or rear panel to a bank of BNC jacks, without the loop of slack a longer assembly would leave behind the plate. Extron builds it on MHR-5 cable, part 22-020-03, so the five legs are true 75 ohm coax rather than thin patch wire; the moulded VGA shell is grounded for ESD protection and the injection moulding carries an overall foil shield against EMI. The jacket is NEC CL2 rated.

Key Capabilities

• 6 in (15 cm) VGA female to five BNC female breakout
• Built on Extron MHR-5 cable, part number 22-020-03
• Five colour-coded 75 ohm female BNC connectors
• Grounded VGA shell for electrostatic discharge protection
• Overall foil shield under the injection moulding
• NEC CL2 rated cable

Where It Is Used

Behind wall plates, floor boxes and rack panels where a VGA connector has to meet an existing RGBHV patch field, and in equipment bays where an Extron interface, switcher or distribution amplifier needs a short, tidy conversion between the two connector styles.

Specifications at a Glance

• Length: 6 in (15 cm)
• Connectors: one female 15-pin HD, five female 75 ohm BNC
• Cable: Extron MHR-5, part number 22-020-03
• Rating: NEC CL2

Also referenced as Extron SYFBNCF/0.5, SYF-BNCF-0-5, part number 2653201.
