Extron SW8 VGA Ars (part number 60-902-21) — an 8x2 VGA-QXGA switcher with fixed and variable stereo audio outputs for full-rack installations.

Eight 15-pin HD inputs accept RGBHV, RGBS, RGsB, RsGsBs, and HDTV component video at up to 350 MHz bandwidth, feeding two simultaneous 15-pin HD outputs — useful for driving a program display and a confidence monitor from the same switch. Each video input has a paired 3.5 mm stereo audio input that follows the selected source to one fixed and one RS-232-adjustable variable audio output, so operators can trim playback level without touching a separate mixer.

Key Capabilities

8x2 VGA-QXGA switching at 350 MHz (-3 dB) bandwidth
Two simultaneous video outputs for dual-display or monitor setups
8-input stereo audio switching to one fixed and one variable output
RS-232-adjustable variable output level, 0 to 100 in 84 dB of range
RS-232 control on a 9-pin D connector
1U full-rack metal enclosure, 6.3 lbs

Where It Is Used

Built for command centers, broadcast studios, and large conference rooms where eight computer sources need to feed two displays at once with synchronized, level-adjustable audio.

Specifications at a Glance

8 VGA/HD-15 + stereo audio inputs, 2 VGA/HD-15 + audio outputs
350 MHz (-3 dB) video bandwidth
Internal 100-240 VAC power supply, 10 watts
1.75" H x 17.5" W x 9.5" D full-rack enclosure
3-year Extron product warranty

Also referenced as Extron SW8VGAArs, SW8-VGA-Ars, part number 6090221.

Specifications

Part Number: 60-902-21

Manufacturer: Extron

Model: SW8 VGA Ars

Condition: New

Gain: Unity

Bandwidth: 350 MHz (-3 dB)

Crosstalk (Video): -68 dB @ 10 MHz

Video Input Number/Signal Type: 8 VGA-QXGA RGBHV, RGBS, RGsB, RsGsBs computer video, and HDTV component video

Video Input Connectors: 8 female 15-pin HD

Video Input Nominal Level: 1.0 Vp-p for Y of component video; 0.7 Vp-p for RGB and for R-Y and B-Y of component video

Video Input Min/Max Levels: Analog: 0.3 V to 1.5 Vp-p with no offset

Video Impedance: 75 ohms

Horizontal Frequency: 15 kHz to 145 kHz

Vertical Frequency: 30 Hz to 170 Hz

Video Input Return Loss: -40 dB @ 5 MHz

Input Coupling: DC

Video Output Number/Signal Type: 2 VGA-QXGA RGBHV, RGBS, RGsB, RsGsBs computer video, and HDTV component video (follows input type)

Video Output Connectors: (2) female 15-pin HD

Video Output Return Loss: -43 dB @ 5 MHz

Video Output DC Offset: ±5 mV with input at 0 offset

Sync Input Type: RGBHV, RGBS, RGsB, RsGsBs, bi-level and tri-level sync

Sync Output Type: RGBHV, RGBS, RGsB, RsGsBs, bi-level and tri-level sync (follows input)

Sync Input Level: 1.0 V to 5.0 Vp-p

Sync Output Level: TTL: 5.0 Vp-p, unterminated

Sync Input Impedance: 510 ohms

Sync Output Impedance: 75 ohms

Max. Propagation Delay: 54 ns

Max. Rise/Fall Time: 4.7 ns

Sync Polarity: Positive or negative (follows input)

Audio Gain: Unbalanced output: +0 dB; balanced output: +6 dB

Audio Frequency Response: 20 Hz to 20 kHz, ±0.05 dB

Audio THD + Noise: 0.01% @ 1 kHz at nominal level

Audio S/N: >90 dB at maximum output (unweighted)

Audio Crosstalk: -45 dB @ 1 kHz, fully loaded

Stereo Channel Separation: >80 dB @ 1 kHz

Audio Input Number/Signal Type: 8 stereo, unbalanced

Audio Input Connectors: 8 3.5 mm female stereo mini jacks; tip (L), ring (R), sleeve (Gnd)

Audio Input Impedance: >10k ohms unbalanced, DC coupled

Audio Input Nominal Level: -10 dBV (316 mV)

Audio Input Maximum Level: +14 dBV (unbalanced) at 1% THD+N

Audio Output Number/Signal Type: 2 stereo, balanced/unbalanced: 1 fixed and 1 variable

Audio Output Connectors: (2) 3.5 mm captive screw connectors, 5 pole

Audio Output Impedance: 50 ohms unbalanced, 100 ohms balanced

Audio Output Nominal Level: +4 dBu (1.23 Vrms), balanced; -10 dBV (316 mVrms), unbalanced

Variable Output Volume Range: 0 to 100 (-84 dB to 0 dB), default = 100 = 0 dB

Audio Output Gain Error: ±0.1 dB channel to channel

Audio Output Maximum Level (Hi-Z): +28 dBu, balanced; +20 dBV, unbalanced at 1% THD+N

Audio Output Maximum Level (600 ohm): +21 dBm, balanced; +18 dBm, unbalanced at 1% THD+N

Serial Control Port: RS-232, 9-pin female D connector

Baud Rate and Protocol: 9600 baud, 8 data bits, 1 stop bit, no parity

Serial Control Pin Configuration: 2 = TX, 3 = RX, 5 = GND

Show Me Contact Closure: Pin 5 of each VGA input connector; the input is active (selected) when pin 5 momentarily goes to ground

Program Control: Extron Universal Switcher control/configuration program for Windows; Extron Simple Instruction Set (SIS)

Power: 100 VAC to 240 VAC, 50/60 Hz, 10 watts, internal

Temperature/Humidity: Storage: -40 to +158°F (-40 to +70°C) / 10% to 90%, noncondensing; Operating: +32 to +122°F (0 to +50°C) / 10% to 90%, noncondensing

Mounting: Rack mount: yes, with optional 1U 9.5" deep rack shelf (RSU 129, #60-190-01 or RSB 129, #60-604-01); Furniture mount: yes, with optional under-desk kit (#70-077-01) or through-desk kit (#70-077-02)

Enclosure Type: Metal

Enclosure Dimensions: 1.75" H x 17.5" W x 9.5" D (1U high, full rack wide) (4.4 cm H x 44.4 cm W x 24.1 cm D); depth excludes connectors

Product Weight: 6.3 lbs (2.9 kg)

Vibration: ISTA 1A in carton (International Safe Transit Association)

Regulatory Compliance (Safety): CE, CUL, UL, C-tick

Regulatory Compliance (EMI/EMC): CE, C-tick, FCC Class A, VCCI, ICES

Product Warranty: 3 years parts and labor

Diagram

Resources

Brochure | SW8 VGA Ars 60-902-21 | SW VGA Series

Brochure | SW8 VGA Ars 60-902-21 | Everlast Power Supplies

Brochure | SW8 VGA Ars 60-902-21 | Alimentatori Everlast

Brochure | SW8 VGA Ars 60-902-21 | Everlast 电源

Brochure | SW8 VGA Ars 60-902-21 | Everlast-Netzteile

Brochure | SW8 VGA Ars 60-902-21 | Fuentes de alimentación Everlast

Brochure | SW8 VGA Ars 60-902-21 | Sources d'alimentation Everlast

Brochure | SW8 VGA Ars 60-902-21 | SW 2 VGA ARs - Spec Sheet

Brochure | SW8 VGA Ars 60-902-21 | SW 2 VGA Rs - Spec Sheet

Brochure | SW8 VGA Ars 60-902-21 | SW 4 VGA ARs - Spec Sheet

Brochure | SW8 VGA Ars 60-902-21 | SW 4 VGA Rs - Spec Sheet

Brochure | SW8 VGA Ars 60-902-21 | SW 6 VGA ARs - Spec Sheet

Brochure | SW8 VGA Ars 60-902-21 | SW 6 VGA Rs - Spec Sheet

Brochure | SW8 VGA Ars 60-902-21 | SW 8 VGA Ars - Bid Sheet

Brochure | SW8 VGA Ars 60-902-21 | SW12 VGA Ars - Bid Sheet

Manual | SW8 VGA Ars 60-902-21 | Audio Connector Wiring Instruction Card

Manual | SW8 VGA Ars 60-902-21 | Cleaning Instruction Card

Manual | SW8 VGA Ars 60-902-21 | SW VGArs / Ars Setup Guide

Manual | SW8 VGA Ars 60-902-21 | SW VGArs /Ars

Manual | SW8 VGA Ars 60-902-21 | SW8/SW12 VGA Ars

Manual | SW8 VGA Ars 60-902-21 | SW8/SW12 VGA Ars setup guide

Specifications | SW8 VGA Ars 60-902-21 | SW2/4/6/8/12 VGA Ars Switchers

Panel Drawing | SW8 VGA Ars 60-902-21 | SW VGA
