Extron SW6 VGArs (part number 60-259-02) — a 6x1 VGA-QXGA switcher for larger rooms that need to route six computer video sources to one display.

Six 15-pin HD inputs accept RGBHV, RGBS, RGsB, RsGsBs, and HDTV component video signals at up to 350 MHz bandwidth, switched to a single output. As with the rest of the SW VGArs line, control runs through the front panel, RS-232, or a shared 9-pin D contact closure, so the SW6 VGArs plugs into an existing control system rather than needing its own dedicated controller.

Key Capabilities

6x1 VGA-QXGA switching at 350 MHz (-3 dB) bandwidth
Accepts RGBHV, RGBS, RGsB, RsGsBs, and HDTV component video
RS-232 control on a 9-pin D connector shared with contact closure
Show Me contact closure reports the active input for status displays
Internal power supply, no external adapter required
1U half-rack metal enclosure, 2.5 lbs

Where It Is Used

Well suited to lecture halls, boardrooms, and command consoles where up to six computers or laptops need controlled, sync-safe access to a shared display without audio switching.

Specifications at a Glance

6 VGA/HD-15 inputs, 1 VGA/HD-15 output
350 MHz (-3 dB) video bandwidth
Internal 100-240 VAC power supply, 10 watts
1.75" H x 8.75" W x 9.5" D half-rack enclosure
3-year Extron product warranty

Also referenced as Extron SW6VGArs, SW6-VGArs, part number 6025902.

Specifications

Part Number: 60-259-02

Manufacturer: Extron

Model: SW6 VGArs

Condition: New

Gain: Unity

Bandwidth: 350 MHz (-3 dB)

Crosstalk (Video): -68 dB @ 10 MHz

Video Input Number/Signal Type: 6 VGA-QXGA RGBHV, RGBS, RGsB, RsGsBs computer video, and HDTV component video

Video Input Connectors: 6 female 15-pin HD

Video Input Nominal Level: 1.0 Vp-p for Y of component video; 0.7 Vp-p for RGB and for R-Y and B-Y of component video

Video Input Min/Max Levels: Analog: 0.3 V to 1.5 Vp-p with no offset

Video Impedance: 75 ohms

Horizontal Frequency: 15 kHz to 145 kHz

Vertical Frequency: 30 Hz to 170 Hz

Video Input Return Loss: -40 dB @ 5 MHz

Input Coupling: DC

Video Output Number/Signal Type: 1 VGA-QXGA RGBHV, RGBS, RGsB, RsGsBs computer video, and HDTV component video (follows input type)

Video Output Connectors: (1) female 15-pin HD

Video Output Return Loss: -43 dB @ 5 MHz

Video Output DC Offset: ±5 mV with input at 0 offset

Sync Input Type: RGBHV, RGBS, RGsB, RsGsBs, bi-level and tri-level sync

Sync Output Type: RGBHV, RGBS, RGsB, RsGsBs, bi-level and tri-level sync (follows input)

Sync Input Level: 1.0 V to 5.0 Vp-p

Sync Output Level: TTL: 5.0 Vp-p, unterminated

Sync Input Impedance: 510 ohms

Sync Output Impedance: 75 ohms

Max. Propagation Delay: 47 ns

Max. Rise/Fall Time: 4.2 ns

Sync Polarity: Positive or negative (follows input)

Serial Control Port: RS-232, 9-pin female D connector (shared with contact closure)

Baud Rate and Protocol: 9600 baud, 8 data bits, 1 stop bit, no parity

Serial Control Pin Configuration: 2 = TX, 3 = RX, 5 = GND

Contact Closure: RS-232 9-pin female D connector (shared with RS-232)

Contact Closure Pin Configuration: 1 = input #1, 4 = input #2, 6 = input #3, 7 = input #4, 8 = input #5, 9 = input #6; active when a pin momentarily shorts to ground

Show Me Contact Closure: Pin 5 of each VGA input connector; the input is active (selected) when pin 5 momentarily goes to ground

Program Control: Extron control/configuration program for Windows; Extron Simple Instruction Set (SIS)

Power: 100 VAC to 240 VAC, 50/60 Hz, 10 watts, internal

Temperature/Humidity: Storage: -40 to +158°F (-40 to +70°C) / 10% to 90%, noncondensing; Operating: +32 to +122°F (0 to +50°C) / 10% to 90%, noncondensing

Cooling: Convection, unvented

Mounting: Rack mount: yes, with optional 1U 9.5" deep rack shelf (RSU 129, #60-190-01 or RSB 129, #60-604-01); Furniture mount: yes, with optional under-desk kit (#70-077-01) or through-desk kit (#70-077-02)

Enclosure Type: Metal

Enclosure Dimensions: 1.75" H x 8.75" W x 9.5" D (1U high, half rack wide) (4.4 cm H x 22.2 cm W x 24.1 cm D); depth excludes connectors

Product Weight: 2.5 lbs (1.1 kg)

Vibration: ISTA 1A in carton (International Safe Transit Association)

Regulatory Compliance: Listings: UL, CUL; Compliances: CE, FCC Class A, VCCI, AS/NZS, ICES

Product Warranty: 3 years parts and labor
