Extron SW4 USB Pro non-LAN USB 10G Switcher
- • Switches 4 hosts (2 USB-C, 2 USB 3.2 Type-B) to shared peripherals at up to 10 Gbps
- • 4-port peripheral hub: 1 USB-C, 1 USB 3.2 Type-A, 2 USB 2.0 Type-A
- • RS-232 control with no Ethernet port, for network-isolated AV control
- • Host and Peripheral Emulation Mode keeps devices enumerated through a switch
- • Hot Key, Auto, and manual switching from the front panel
- • 3-year Extron warranty; 7-year Everlast power supply warranty
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron SW4 USB Pro non-LAN (part number 60-1834-02) — a four-input USB 10Gbps switcher without Ethernet, for RS-232-only control environments.
SW4 USB Pro non-LAN lets up to four host PCs or laptops share one set of USB peripherals — camera, keyboard, mouse, and storage — switching between hosts at the front panel or over RS-232, at data rates up to USB 10Gbps with full backward compatibility to USB 1.1. This non-LAN variant omits the Ethernet control port found on the standard SW4 USB Pro, making it a fit for installations that keep AV control off the network. Host and Peripheral Emulation Mode keeps both the host and connected peripherals continuously enumerated in the background, so switching between hosts doesn't force devices to re-enumerate or drop out.
Key Capabilities
- Switches 4 hosts (2 USB-C, 2 USB 3.2 Type-B) to shared peripherals at up to 10 Gbps
- 4-port peripheral hub: 1 USB-C, 1 USB 3.2 Type-A, 2 USB 2.0 Type-A
- RS-232 control with no Ethernet port, for network-isolated AV control
- Host and Peripheral Emulation Mode keeps devices enumerated through a switch
- Hot Key, Auto, and manual switching from the front panel
Where It Is Used
SW4 USB Pro non-LAN is specified in secure or network-isolated rooms that need the same four-host USB switching as the standard SW4 USB Pro but must keep the switcher off the building network, controlling it instead through an RS-232-connected control processor.
Specifications at a Glance
- USB host ports: 4 (2 USB-C, 2 USB 3.2 Type-B), up to 10 Gbps
- Peripheral hub: 4 ports (USB-C, USB 3.2 Type-A, 2x USB 2.0 Type-A)
- Control: RS-232 only, no Ethernet
- Power: External 12 VDC, 24 W supply, 18.55 W device draw
- Enclosure: 1U half-rack, 1.75" H x 8.75" W x 3.0" D, 2.0 lbs (0.9 kg)
Also referenced as Extron SW4USBProNonLAN, SW4-USB-Pro-non-LAN, part number 60183402.
