Extron SW4 USB Plus 4-Input USB Switcher
- • 4-input USB 2.0 switcher with host/peripheral emulation mode
- • Emulation prevents dropped USB enumeration during switching
- • Two built-in USB hubs, double the standard SW4 USB
- • 500 mA of shared USB power across four output ports
- • RS-232 control with RS-232 pass-through for control chains
- • 1U half-rack metal enclosure at 2.0 lbs
Product discontinued.
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron SW4 USB Plus (part number 60-954-01) — a 4-input USB 2.0 switcher with host and peripheral emulation for USB links that need to stay connected through a switch.
Standard USB switchers force devices to re-enumerate on every change, which can drop mice, tablets, or annotation devices mid-session. The SW4 USB Plus adds an optional emulation mode that continuously mimics host and keyboard/mouse communication inside the switcher, so connected peripherals see a stable link even while inputs change. Two built-in hubs and RS-232 pass-through round out a design meant for demanding shared-control rooms.
Key Capabilities
- 4 USB type B host inputs switched to a shared 4-port USB hub
- Optional host/peripheral emulation mode to prevent dropped enumeration
- Two built-in USB hubs versus one on the standard SW4 USB
- 500 mA of shared power across the four output ports
- RS-232 control with RS-232 pass-through for AV control chains
- 1U half-rack metal enclosure at 2.0 lbs
Where It Is Used
Ideal for interactive whiteboard and annotator-based classrooms, judicial benches, and KVM-style workstations where a USB peripheral must never appear to disconnect mid-switch.
Specifications at a Glance
- 4 USB type B inputs / 4 USB type A outputs
- USB 2.0 compatible, up to 480 Mbps
- External 12 VDC, 18 W power supply
- 1.6" H x 8.6" W x 3.0" D half-rack enclosure
- 3-year product warranty, 7-year Everlast power supply warranty
Also referenced as Extron SW4USBPlus, SW4-USB-Plus, part number 6095401.
