Extron SW4 USB (part number 60-953-01) — a 4-input USB 2.0 switcher that lets up to four host computers share one bank of USB peripherals.

Each of the four USB type B inputs can be selected from the front panel, over RS-232, or through a contact closure, routing keyboard, mouse, or annotation traffic to a shared 4-port USB hub. A built-in hub and port status indication make it straightforward to add to a multi-source room without a dedicated switching computer, and RS-232 pass-through keeps the SW4 USB transparent to any existing control system.

Key Capabilities

4 USB type B host inputs switched to a shared 4-port USB 2.0 hub
USB 2.0 compatible, handling speeds up to 480 Mbps
500 mA of shared power across the four output ports
RS-232 control with RS-232 pass-through for chained control systems
5-pole contact closure input covering all four inputs
1U half-rack metal enclosure, 2.0 lbs

Where It Is Used

Well suited to multi-presenter classrooms, boardrooms, and interpreter suites where several laptops need momentary, controlled access to shared USB devices like document cameras or interactive displays.

Specifications at a Glance

4 USB type B inputs / 4 USB type A outputs
USB 2.0 compatible, up to 480 Mbps
External 12 VDC, 18 W power supply
1.6" H x 8.6" W x 3.0" D half-rack enclosure
3-year product warranty, 7-year Everlast power supply warranty

Also referenced as Extron SW4USB, SW4-USB, part number 6095301.

Specifications

Part Number: 60-953-01

Manufacturer: Extron

Model: SW4 USB

Condition: New

USB Specification: USB 2.0 compatible

USB Data Rates: Low speed (1.5 Mbps), full speed (12 Mbps), high speed (480 Mbps)

USB Input Connectors: 4 female USB type B

USB Device Port Connectors: 4 female USB 2.0 type A

Available USB Power: 500 mA shared on four ports

Maximum Built-in USB Hubs: 1

Serial Control Port: (1) RS-232, 3.5 mm captive screw connector, 3 pole; (1) RS-232 pass-through, 3.5 mm captive screw connector, 3 pole

Baud Rate and Protocol: 9600 baud, 8 data bits, 1 stop bit, no parity

Program Control: Extron Simple Instruction Set (SIS)

Power Supply: External; Input: 100-240 VAC, 50-60 Hz; Output: 12 VDC, 1.5 A, 18 watts

Power Consumption (Device): 11 watts, 12 VDC

Power Consumption (Device and Power Supply): 14 watts, 100-240 VAC, 50-60 Hz

Temperature/Humidity: Storage: -40 to +158°F (-40 to +70°C) / 10% to 90%, noncondensing; Operating: +32 to +122°F (0 to +50°C) / 10% to 90%, noncondensing

Cooling: Convection, no vents

Mounting: Rack mount: yes, with optional rack shelf; Furniture mount: yes, with optional under-desk mounting kit

Enclosure Type: Metal

Enclosure Dimensions: 1.6" H x 8.6" W x 3.0" D (1U high, half rack wide) (4.1 cm H x 21.8 cm W x 7.6 cm D); depth excludes connectors

Product Weight: 2.0 lbs (0.9 kg)

Regulatory Compliance: CE, c-UL, UL, C-tick, FCC Class A, ICES, RoHS, VCCI, WEEE

Product Warranty: 3 years parts and labor

Everlast Power Supply Warranty: 7 years parts and labor

Diagram

Resources

Brochure | SW4 USB 60-953-01 | SW USB Series

Brochure | SW4 USB 60-953-01 | Everlast Power Supplies

Brochure | SW4 USB 60-953-01 | Alimentatori Everlast

Brochure | SW4 USB 60-953-01 | Everlast 电源

Brochure | SW4 USB 60-953-01 | Everlast-Netzteile

Brochure | SW4 USB 60-953-01 | Fuentes de alimentación Everlast

Brochure | SW4 USB 60-953-01 | Sources d'alimentation Everlast

Manual | SW4 USB 60-953-01 | Cleaning Instruction Card

Manual | SW4 USB 60-953-01 | SW USB Series User Guide

Manual | SW4 USB 60-953-01 | SW USB Setup Guide card

Specifications | SW4 USB 60-953-01 | SW USB Series

Panel Drawing | SW4 USB 60-953-01 | SW USB Series
