Extron SW2 VGArs 60-257-02

Extron SW2 VGArs 2x1 VGA-QXGA Switcher with Sync 60-257-02

Extron SW2 VGArs 2x1 VGA-QXGA Switcher with Sync 60-257-02

Manufacturer: Extron

Type: Switchers

Extron SW2 VGArs 2x1 VGA Switcher

  • • 2x1 VGA-QXGA switching at 350 MHz (-3 dB) bandwidth
  • • Accepts RGBHV, RGBS, RGsB, RsGsBs, and HDTV component video
  • • RS-232 control on 9-pin D connector shared with contact closure
  • • Show Me contact closure reports the active input
  • • Internal 100-240 VAC power supply, no external adapter
  • • 1U half-rack metal enclosure, 2.5 lbs

Product discontinued.

Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!

SKU: EXTRON-SW2VGARS-6025702

Details

Extron SW2 VGArs (part number 60-257-02) — a 2x1 VGA-QXGA switcher built for routing two computer video sources to a single display with full sync support.

The SW2 VGArs accepts RGBHV, RGBS, RGsB, and RsGsBs signals plus HDTV component video across two 15-pin HD inputs, and passes whichever source is active out to one 15-pin HD output at up to 350 MHz bandwidth. Switching is available from the front panel, RS-232 command, or a shared 9-pin D contact closure connector, so the unit drops into a room's existing control wiring without adding a computer to manage the switch itself.

Key Capabilities

  • 2x1 VGA-QXGA switching at 350 MHz (-3 dB) bandwidth
  • Accepts RGBHV, RGBS, RGsB, RsGsBs, and HDTV component video
  • RS-232 control on a 9-pin D connector shared with contact closure
  • Show Me contact closure reports the active input for status displays
  • Internal power supply — no external power brick to manage
  • 1U half-rack metal enclosure, 2.5 lbs

Where It Is Used

Fits classrooms, conference rooms, and simple presentation switching where two laptops or PCs need clean, sync-preserving access to one VGA display or projector without a full matrix switcher.

Specifications at a Glance

  • 2 VGA/HD-15 inputs, 1 VGA/HD-15 output
  • 350 MHz (-3 dB) video bandwidth
  • Internal 100-240 VAC power supply, 10 watts
  • 1.75" H x 8.75" W x 9.5" D half-rack enclosure
  • 3-year Extron product warranty

Also referenced as Extron SW2VGArs, SW2-VGArs, part number 6025702.
