Details

Manufacturer: Extron | Model: SSI 100C Lens | Part number: 70-1349-01 (also written 70134901)

The Extron SSI 100C Lens (70-1349-01) is the replacement two-sided acrylic lens for the SSI 100C ceiling-mount system status indicator. The lens clips into the SSI 100C body without tools. This part number is the ceiling-mount lens; the wall-mount SSI 100W uses a different lens (70-1348-01). Engraved versions are available for custom room identification.

Key capabilities

Replacement lens specifically for the SSI 100C (60-1961-01) ceiling-mount unit
Two-sided acrylic diffuses LED illumination for an architectural finish
Tool-free snap-in installation for quick field replacement
Available in blank or custom-engraved versions for room labeling
Do not confuse with the SSI 100W wall lens (70-1348-01)

Where it is used

Field replacement when an SSI 100C ceiling lens is damaged, or when switching from blank to engraved for improved room identification.

Specifications at a glance

Compatible indicator: Extron SSI 100C (60-1961-01) only
Lens material: two-sided acrylic
Warranty: 3-year Extron parts and labor

Also referenced as Extron SSI100CLens, SSI-100C-Lens, part number 70134901.

Specifications

Part Number: 70-1349-01

Manufacturer: Extron

Condition: New

+24 V output port: (1) 3.5 mm captive screw connector, 2 pole

Height: 2.75" (7.0 cm)

Calendar mode: 2 colors (green and red)

Ceiling tile mount: US 4S J-Box with 1 gang reducer cover plate or included 1-gang plastic mud ring, T Grid hanger with 2 screws and a magnetic faceplate

Configuration software: Global Configurator Plus and Professional

Connector: (2) 3.5 mm captive screw connector, 2-pole

Cooling: Convection

DHCP: off

DNS: 127.0.0.1

Default gateway: 0.0.0.0

Device: 9.6 watts

Device and power supply: 12.6 watts

Digital input mode: (using 1 digital input port) 2 colors (green and red)

Enclosure dimensions: See the SSI 100C and SSI 100W dimensions diagrams below:

Enclosure type: Plastic faceplate and metal rear enclosure

Ethernet data rate: 10/100Base-T, half/full duplex with autodetect

Ethernet protocol: DHCP, DNS, HTTP, HTTPS, ICMP, NTP, SFTP, SMTP, SNMP, SSH, TCP/IP, UDP/IP

Flash: 512 MB

IP address: 192.168.254.254

Input: 100-240 VAC, 50-60 Hz

Input impedance: >10k ohms

Input voltage range: 0-24 VDC

Link speed and duplex level: autodetected

Number/type: (2) digital inputs (configurable)

Open Ceiling Pendant mount: US 4S J-box, ½” down tube to US 4S J-Box (1 gang reducer cover plate) with 2 screws and magnetic faceplate

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Output: +24 VDC, 50 mA, fixed, non-switchable

PoE Ethernet host port: (1) female RJ-45

Power input: Power over Ethernet (PoE) (complies with PoE 802.3af, class 3) or 12 VDC from external power supply (sold separately)

Power supply (sold separately): External, not included

Product warranty: 3 years parts and labor

Product weight: SSI 100W – 0.7 lbs (0.3 kg) device with blank lens SSI 100W – 0.9 lbs (0.4 kg) device with engraved lens SSI 100W – 0.4 lbs (0.2 kg) engraved lens only SSI 100C – 1.0 lb (0.45 kg) device with blank lens SSI 100C – 1.3 lbs (0.6 kg) device with engraved lens SSI 100C – 0.7 lbs (0.3 kg) engraved lens only

Programmable pullup: 2k ohms to +5 VDC

Programming software: ControlScript Programming

Regulatory compliance: CE, CUL, UL, C-tick, FCC Class A, ICES, VCCI, Complies with the appropriate requirements of RoHS, WEEE

Resource management software: GlobalViewer Enterprise

SDRAM: 512 MB

SPD mode: up to 16 million colors defined in hex code (example: FF0000)

SSI 100C Custom Sign: 9.01” (229 mm) W x 2.91” (74 mm) D x 6.07" (154 mm) H

SSI 100W Custom Sign: 6.01" (153 mm) H x 2.91" (74 mm) D x 5.79" (147 mm) W

Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Subnet mask: 255.255.255.0

Threshold high to low: >2.0 VDC

Threshold low to high: >2.8 VDC

Utilities: Toolbelt, Room Agent

Wall mount: US 1 gang J-Box or included plastic mud ring with 2 screws and faceplate
