Extron SMB 115 Five-Gang Surface Mount Box
- • Extron SMB 115 five-gang surface mount box, white
- • 115 degree front angle
- • CE, RoHS and WEEE compliant
- • Sales, replacement and exchange
- • Part# 70-1286-05 / 70128605
Need service or repair? No matter the age, brand, or manufacturer Ampronix can repair it! Free, no charge for initial evaluations!
Couldn't load pickup availability
Details
Details
Extron SMB 115 (part number 70-1286-05, white) - the white finish of the widest box in Extron's SMB 110 Series, carrying five US gang-size plates.
A five-gang enclosure is a lot of hardware to put on a table, so finish is a real design decision. White lets the box read as part of a pale worktop or a light teaching wall rather than a black slab bolted to the surface. Function is unchanged: five gang positions behind a 115 degree angled face, three base cable openings for the bundle, and a mounting scheme that never requires the furniture to be cut.
Key Capabilities
- Accepts five US gang-size Extron wallplates, AAP mounting frames or MediaLink controllers.
- Measures 10.16" W x 4.40" H x 4.35" D (258 x 112 x 111 mm) and weighs 1.3 lbs (0.6 kg).
- Three 1.25" x 1.30" (32 x 33 mm) cable openings plus a 0.40" (10 mm) rear slot across the width.
- Placed loose, screwed down with the supplied #8 wood screws, or clamped to 0.38" to 2.00" tops.
- Cable strain relief and cover strips supplied, including the rear cover strip used at this size.
- Metal body, high impact plastic end caps and a #6-32 grounding stud in the base plate.
Where It Is Used
Large light-finish conference and council tables, lecture theatre teaching positions, library and study areas, healthcare workstations and laboratory benches. The spare gangs make it a sensible choice for phased projects where more plates will be added later.
Specifications at a Glance
- Colour: white; the black version is part number 70-1097-05
- Front angle: 115 degrees
- Optional Table Clamp Kit: 70-1160-13 white, 70-1160-12 black
- Regulatory compliance: CE, RoHS, WEEE
- Warranty: 3 years parts and labor
Frequently asked questions about the Extron SMB 115 Five-Gang Surface Mount Box White
Does Ampronix sell the Extron SMB 115 Five-Gang Surface Mount Box White?
Yes. Ampronix is an authorized Extron distributor and sells the Extron SMB 115 Five-Gang Surface Mount Box White (70-1286-05). Call Ampronix for a quote.
Does Ampronix offer replacement and exchange for the Extron SMB 115 Five-Gang Surface Mount Box White?
Yes. Ampronix provides sales, replacement and exchange for the Extron SMB 115 Five-Gang Surface Mount Box White. Call Ampronix for a quote.
Is the Extron SMB 115 Five-Gang Surface Mount Box White listed under other names?
Yes. The Extron SMB 115 Five-Gang Surface Mount Box White is also referenced as Extron SMB115, SMB-115, part number 70128605.
What are the key features of the Extron SMB 115 Five-Gang Surface Mount Box White?
Key points: Accepts five US gang-size Extron wallplates, AAP mounting frames or MediaLink controllers; Measures 10.16" W x 4.40" H x 4.35" D (258 x 112 x 111 mm) and weighs 1.3 lbs (0.6 kg); Three 1.25" x 1.30" (32 x 33 mm) cable openings plus a 0.40" (10 mm) rear slot across the width; Placed loose, screwed down with the supplied #8 wood screws, or clamped to 0.38" to 2.00" tops. Call Ampronix to confirm details for your application.
Also referenced as Extron SMB115, SMB-115, part number 70128605.
